EPR/XLPE Insulated Shipboard power cable 0.6/1KV
Rating voltage: 0.6/1KV 1.8/3kV 3.6/6KV 6/10KV 8.7/15KV
Specification &standards
IEC60228 IEC60092-350 IEC60092-359
IEC60092 351 IEC60332-1 IEC60332-3 Cat.A
IEC61034-2 IEC 60754-2 3A
Construction:
Conductor:tinner copper
Insulated:EPR or XLPE
Filler
Tape
Inner sheathe:PCP/CSP/PVC/PO(SHF1,SHF2)
Armored:tinned copper wire braid(Galvanized steel wire braid)
Outer Sheath:PVC/PCP/PO(SHF1,SHF2)
Flammability Features:
DA:Single cable flame retardant
SA:Bunched cable flame retardant
SC:Bunched cable flame retardant,halogen-free,low-smoke,low-toxicity
Specifications:
Cores:1.2.3.4.4.7.10.12.14.16.19.24.27.30.33.37
NominalCross-section Areas:0.75mm2,1mm2,1.5mm2,2.5mm2,4mm2,6mm2,10mm2,16mm2,25mm2,
35mm2,50mm2,70mm2,95mm2,120mm2,150mm2,185mm2,240mm2,300mm2
Applicant:
The marine electrical cable is intended for power,lighting and control system of shipboard and off-shore building,and it is also available to metallurgical chemical works,power planted and mines etc.
Certificates:
CCS,LR,ABS,DNV,BV,GL,NK,KR,RINA,90
The radius of bend for the installation of marine cables
| Cable structure features | Over diameter of cable(D) | Minimum internal bending radius |
| Metal braided armored | Any value | 6D |
| Non-armored | D≤25 | 4D |
| D25 | 6D |
Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220, 000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, large-scale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables. Submersible oil pump cables, . )and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa, Congo, Middle East and Southeast Asia countries and so on.
Products: XLPE insulating power cables with voltage up to 35kV, PVC insulated power cables, mining cable, general rubber sheathed flexible cable, Submersible oil pump cable, locomotive-vehicle cables, elevator cable, shipboard cable, nuclear station cables, pre-fabricated branch cables, ABC cables, control cables, special cables, the motor winding connecting conductors, aluminum stranded conductor (AAC) and aluminum stranded steel-core reinforced conductor (ACSR) so on.
