Product Specifications
| Prod Model: |
BT-709 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Thermostat |
| Temperature Range: |
5 - 35 Degree |
| Switch Current Rating: |
< 0.3A |
| Power Supply: |
220V AC±15% 50-60Hz |
| Sensing Element: |
Ntc |
| Housing Material: |
Retardant ABS Material |
| Display: |
Large Character LCD Display |
| Dimensions: |
86*86*13.5mm |
| Factory: |
Yes |
| OEM: |
Is Welcome |
| Usage: |
Air Conditioner |
| Certification: |
CCC |
| Control Type: |
Digital |
| Type: |
Temperature Controller |
| Display Type: |
LCD |
| Material: |
Retardant ABS Material |
| Brand: |
Bowei |
Product Description
Specifications
24/110/220Vac
embeded mounting
On/off control
2pipe / 4pipe
Sensing element
| NTC |
Accuracy
| ± 0.5ºC |
Set-point range
| 5ºC to 40ºC |
Display range
| 0~40ºC |
Operating Humidity
| 5~80%RH (non-condensing) |
Power supply
| AC 220V ± 10%, 50Hz |
Switch current rating: Resistive
| 2A, Inductive: 1A |
Rated Power
| < 2 W |
Housing
|
ABS + PC Flame Retardant
|
Protection Class
| IP30 |
Cool, Heat and Vent.
Room Temperature Setting
Detect and Display Room Temperature
Manual/Auto Fan Speed
Low Temperature Protection
Clock(Optional)
Sleep(Optional)
Infrared Remote Control (Optional)
Blue Backlight(Optional)
5+2 or 7 days 4 periods Programmable (Optional)
Attractive modern styling makes this thermostat ideal for locating in the
occupied space
Digital LCD display of room ambient temperature and user selected
temperature setting on demand
Adjustable heating/cooling/ventilating mode control
Adjustable manual 3-speed or automatic fan speed control and on/off control
output for valve
Model available for cycling fan control
Thermostat mounted directly onto a wall or standard junction box
Model available for 24Vac, 85-260Vac, power input also
Reliable DC power supply by transformer
Reliable output by relays
Applications:
The thermostats are stand-alone microprocessor based thermostats with LCD display. The thermostats are designed to on/off control the fans, valves, dampers or electric heaters in fan coil units, air-conditioners and heating applications.
Models are available for heating/cooling/ventilating control of 2-pipe or 4-pipe fan coil units.
The fan speed can be manually controlled by the fan speed control pushbutton. It is wired to run high/medium/low speed continuously or to automatically change the fan speed, while with other models there is a choice of running the fan continuously, or cycling it with the thermostat.
