Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,CIF,EXW |
Min Order: | 500000/Piece |
Pay Type: | L/C,T/T |
1) A variety of specifications available.
2) Satisfy various technical request
3) Lower medium spoilage
4) Good insulation performance and high temperature resistance
5) Stiffness texture
6) Used in all electric products, electric heating products and wear resistant machinery parts.
We can supply the products according to customer's drawings, samples and performance requirement.
Performance For Industrial Ceramic | ||||||
Item |
Unit | 95 Al 2 O 3 | 96 Al 2 O 3 | 99 Al 2 O 3 | ||
Physical Characteristics | Heat resistance | 0 C | 1500 | 1550 | 1800 | |
Bulk density | g/cm 3 | 3.6 | 3.6 | 3.9 | ||
Water absorption | % | 0 | 0 | 0 | ||
Mechanical Characteristics |
Flexural strength | Mpa | 320 | 340 | 360 | |
Hardness vickers | Gpa | 12.2 | 13.5 | 15.6 | ||
Elastic modulus | Gpa | 280 | 320 | 370 | ||
Poisson's ratio | 0.22 | 0.23 | 0.23 | |||
Thermal Characteristics | Linear expansion coefficient | (20-500 0 C) 10 -6 / 0 C | 7.1 | 7.2 | 8 | |
Thermal conductivity | w/(m.k) | 16 | 24 | 32 | ||
Specific Heat | *10 -3 J/(kg*K) | 0.78 | 0.78 | 0.9 | ||
Electrical Characteristics | Dielectric constant (1MHZ) | - | 9 | 9.4 | 9.9 | |
Dielectric loss angle | *10 -4 | 15 | 5 | 1 | ||
Dielectric strength | *10 6 V/m | 12 | 15 | 15 | ||
Processing technology | ||||||
Process range (mm) | ||||||
Outside Diameter | 1---300 | |||||
Inside Diameter | 0.5---300 | |||||
Length | 0.5---600 | |||||
Accuracy of working (mm) | ||||||
Perpendicularity | 0.001 | |||||
Concentricity | 0.001 | |||||
Roundness | 0.0005 | |||||
Straightness | 0.005 | |||||
Parallelism | 0.01 | |||||
Planeness | 0.005 | |||||
Roughness | 0.005 | |||||
Fit clearance | 0.005 |
Prod Model: | XDQ-CH |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Use For: | Heater Part |
Temperature Resistance: | 1000 Degree |
Shape: | Butterfly Shape Cylinder Shape Q Shape |
Customized: | Yes |
Normal Size: | Od10 12 14 |
Style: | Steatite Aliminum Oxide Ceramic |
Certificate: | RoHS,SGS |
Structure: | Post Insulator |
Material: | Porcelain |
Type: | A Type Insulator |
Application: | High-temperature |
Brand: | Xinda |
Certification: | CB |
