Infrared Laser Diode Module
Elite could supply industrial infrared laser diode module with wavelengths listed below. It could be customized into different dot, line or cross beams. The main feature is high stability, high reliability and long life span of more than 10, 000hrs. It could be applied in infrared lighting, military collimation, infrared surveying, medical usage, etc.
780nm 5mw ~ 3000mw
808nm 5mw ~ 5000mw
830nm 5mw ~ 3000mw
850nm 5mw ~ 3000mw
980nm 5mw ~ 5000mw
Low output power Series (Dot, Line, Cross)
EL780D05IG1, EL780D05IG2, EL780D05IG3, EL780D05IG4, EL780D05IG8, EL780D05IG9
EL808D05IG1, EL808D05IG2, EL808D05IG3, EL808D05IG4, EL808D05IG8, EL808D05IG9
EL830D05IG1, EL830D05IG2, EL830D05IG3, EL830D05IG4, EL830D05IG8, EL830D05IG9
EL850D05IG1, EL850D05IG2, EL850D05IG3, EL850D05IG4, EL850D05IG8, EL850D05IG9
EL980D05IG1, EL980D05IG2, EL980D05IG3, EL980D05IG4, EL980D05IG8, EL980D05IG9
Note: The difference of models listed is with different aperture and divergence. Some are suitable for short distance working (<2m), while some are suitable for far distance working (>50m). Please contact us, we will design a customized product especially suitable for your application.
High output power Series ( with TEC Cooler)
HL780-500M, HL780-1000M, HL780-2000M, HL780-3000M
HL808-500M, HL808-1000M, HL808-2000M, HL808-3000M, HL808-5000M
HL830-500M, HL830-1000M, HL830-2000M, HL830-3000M
HL850-500M, HL850-1000M, HL850-2000M, HL850-3000M
HL980-500M, HL980-1000M, HL980-2000M, HL980-3000M, HL980-5000M
Industrial Laser
As the attach files
Advantage:
-compact size
-FDA ISO2000: 2008 IEC
-SGS TUV assessed supplier
-Wide work temperature
-high reliability
Key Feature
1. High quality
2. High Stability
3. High reliability
4. APC driving circuit
5. Low cost
6. Long Life
Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments
5. Wide range of applications from industrial positioning, barcode scan, medical instruments, detecting instruments, laser instruments, Gun laser sight, laser preformance systems, laser tools etc.
*Elite's facilities and products are in full compliance with ISO9001: 2008, FDA IEC. GB standard.
*Green Laser Module which has a wide working temperature ranging from -10-50.
*Green laser module are packaged in industrial leading compact sizes of Φ 8*28mm and 10*30mm
*Share your ideas with us, We will provide the best solution.
Note:
1, The DOT series laser diode module is customized product with different plastic and glass lens. Thus the laser shape could be an ellipse or circle with various divergence, beam size and aperture. The output power is adjustable according to customers' requirements.
2, Dimensions are customized according to customer's needs except the ones listed.
3, More models could be offered such as EL65D05IGX, EL65D05IG6, EL65D05IG7, EL65D05IG10, EL65D05IG15, etc. Elite is continually developing new models and launching to me.
QC Flow
1 Professional Power Meter for double check
2 Qualified professional staff for the beam size/line thickness testing
3 Strictly surface Inspection before load to the warehouse.
Sent Us Inquiry Now and Pls mention the following points:
1 Wavelength
2 Output Powder
3 Housing Dimension
4 Work distance
5 Beam size/Line thickness
About ELITE
|
* ELITE OPTOELECTRONICS CO.,LTD was found in 2003 year.
*ELITE is a professional designer and manufacturer of laser diode modules,DPSS laser modules and related laser
instruments,Benefited from our experienced R&d Team and Large-scaled production capacity.
*ELITE becomes one of the world-class laser diode module suppliers.
|
Payment Method
|
*T/T Accept USD,EUR,HKD,GBP etc(Many currency ,suit for all clients)
*Western Union:Quickly to the account ,Priority in delivery
*Paypal:A global leader in online payment,
|
Shipping
|
UPS FedEx TNT DHL EMS ,3-7Days arrive the specified address After Payment. |
ITEM
|
Specifications
|
Spectral Range
|
Violet
|
Blue
|
Red
|
Red
|
Infrared
|
Infrared
|
Infrared
|
Infrared
|
Infrared
|
Wavelength
|
405nm
|
445nm
|
635nm
|
650nm
|
780nm
|
808nm
|
830nm
|
850nm
|
980nm
|
LD Powder(mW)
|
5-10.
|
5-60
|
5-180
|
5-150
|
5-200
|
50-5000
|
5-100
|
5-100
|
20-5000
|
Operating Current
|
25-5000mA
|
Input Voltage
|
2.6-5.5VDC or 9.0-15.0VDC
|
Operating Temp
|
(-10–50)
|
Storage Temp
|
(-40–80)
|
Powder Stablity
|
>98%(@2.7-5.5VDC)
|
Powder Stablity
|
>95%(@-10-50)
|
MTBF
|
>10000Hrs
|
Circuit Protection
|
Static,Surge,and Reverse Polarity Protected
|
Case Material
|
Brass or Aluminium
|
Beam Pattern
|
Dot,Line,Cross
|
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
