Usually ladder belt is called Chocolate Conveyor Stainless Steel Belt. Which is made by assembling the sucessively bent wire...
Advantages:
1. Positive sprocket drive Stainless Steel wire mesh belt ensures stable running.
2. The rotation diameter of stainless steel conveyor wire mesh belt is small, so that smooth products transfer is ensured.
3. This kind of conveyor wire mesh belt is washed easily.
4. Because of large open air of mesh bekt, high air permeablity and hydration are ensured.
5. Reinforcement plate links are made for heavy load and high speed.
| Ladder Belt (standard specification) |
| Pitch (mm) | 5 | 6 | 7 | 7 | 10 | 13 | 15 | 15 | 10 | 20 | 20 | 20 | 19 |
| Wire diameter(mm) | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 3 | 3 | 3.2 | 3.5 | 5 |
| Minimum span(mm) | 30 | 30 | 30 | 30 | 30 | 40 | 40 | 50 | 60 | 100 | 130 | 150 | 300 |
| Overall width(mm) | 300~4200
|
New-style Mesh Belt Description
1. Material: stainless steel 304, 316, 316L or etc, and plastic
2. New style: this new products are approved by WMB belt's engineers this year.
The belt could be in any style, using any specification. Such as flat wire kind, using different
pitch of flat wire size, or some other kinds of belt in different pitches. Any size, any style is available in our company.
3. Application of the new style: food industry, architectural industry, or any other industries
Stainless steel mesh high temperature belt
Description:
These belts can be used for sintering,brazing,hardening,firing,tempering,lehr...etc.It is important to select belt type and material which can ensure high temperature.
Applications:
Frozen food machinery,canned food machinery,seafood machinery,continuous baking machinery,heat treatment machinery,glass machinery,chemical machinery,general purpose conveyors,special convetors.
Materials:
SUS 304#(corrosion resistance),SUS 316#(Acid Resistance or Alkali Resistance),SUS 310S,314#,330#(heat resistance),Soft steel wire,Zinced Steel wire and other specified wire,
Advantages:
1.20 years experience of production mesh belt
2.high quality ensure
3.easily washed
4.High open area ensures air permeablity and hydration capacity.
5.Reinforcement plate links are made for heavy load and high speed.
