Foton Lovol Strong Power, Low Oil Consumption Hydraulic Bulldozer (FT140-1/FTY165-2/FSD7)
Price: |
Negotiable/Piece |
Trade Terms: |
FOB,EXW,CIF |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T |
Product Specifications
Prod Model: |
FT140-1,FT165-2,FTY165-2,FSD6G,FSD7,FSD8B,FSD9 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type Of Blade: |
Angle Blade/Straight Tilt Blade/U Blade |
Walking Mode: |
Crawler |
Load And Unload Method: |
Front Discharge |
Certification: |
ISO9001: 2000 |
Condition: |
New |
Type: |
Bulldozer |
Product Description
Foton Lovol Strong power,low oil consumption Hydraulic Bulldozer(FT140-1/FTY165-2/FSD7)
Bulldozer is applied to excavating cut slope, building road embankment, backfilling foundation pit, wiping out barriers, sweeping snows and leveling ground etc.
It also can be used to complete shoveling and stacking operations of loose materials for short distance as an auxiliary shovel. If it is equipped with a ripper, it may complete pre-loosening operation.Main Configuration Parameters of Lovol BulldozerModel | FT140-1 | FT165-2 | FTY165-2 | FSD6G | FSD7 | FSD8B | FSD9 |
Performance Parameters | Type | Bulldozer | Bulldozer | Bulldozer | Bulldozer | High-driving Bulldozer | High-driving Bulldozer | High-driving Bulldozer |
Type of Blade | Straight tilting blade | Angle blade | Straight tilting blade | Angle blade | Straight tilting blade | U-type blade | Straight tilting blade | Straight tilting blade | Straight tilting blade | Straight tilting blade |
Operating Mass | 16500 | 16600 | 17200 | 17300 | 17600 | 17700 | 16500 | 23800 | 36800 | 44580 |
Ground Pressure kPa | 62.9 | 63.3 | 66.7 | 67 | 68.2 | 68.5 | 55.23 | 71.9 | 93 | 102 |
Distance between Track Centers mm | 1880 | 1880 | 1880 | 1880 | 1880 | 1880 | 1880 | 1980 | 2083 | 2250 |
Minimum Ground Clearance mm | 400 | 400 | 352.5 | 352.5 | 352.5 | 352.5 | 445 | 404 | 556 | 517 |
Gradeability ° | 30/25 | 30/25 | 30/25 | 30/25 | 30/25 | 30/25 | 30/25 | 30/25 | 30/25 | 30/25 |
Capacity of Blade m3 | 4.5 | 4 | 5 | 4.9 | 5 | 7.4 | 4.5 | 8.4 | 11.24 | 13.5 |
Width of Blade mm | 3297 | 3762 | 3297 | 3762 | 3297 | 4240 | 3297 | 3500 | 3940 | 4314 |
Maximum Digging Depth mm | 400 | 400 | 420 | 377 | 420 | 377 | 592 | 498 | 582 | 614 |
Overall Dimensions (L× W × H) | 5336×3297×2842 | 5486×3762×2842 | 5416×3297×3160 | 5716×3762×3160 | 5416×3297×3160 | 5416×4240×3160 | 5037×3297×3077 | 5677×3500×3402 | 7751×3940×3549 | 6592×4314×3970 |
Engine | Model | Weicha WD10G156E26 | Weicha WD10G156E26 | Weicha WD10G156E26 | Shangchai C6121ZG72B | Cummins NTA855-C280S10 | Cummins NTA855-C280S10 | Cummins NTA855-C280S10 |
Rated Engine Speed rpm | 1800 | 1850 | 1850 | 1900 | 2100 | 2100 | 1800 |
Rated Power KW | 104 | 121 | 121 | 119 | 169 | 235 | 316/430 |
Maximum Torque Nm/rpm | 780/1200 | 830/1000-1200 | 830/1000-1200 | 770/1400 | 1097/1500 | | |
Fuel consumption rate g/KWh | ≤215 | ≤215 | ≤215 | 215 | ≤235 | | |
Foton Lovol International Heavy Industry Co., Ltd. (Foton Lovol) is a large-scale industrial equipment manufacturing enterprise primarily engaging in agricultural equipment, construction machinery, vehicles, core components, financial services and other businesses. Founded in 1998, the company now has total assets of 16.1 billion Yuan and 16, 000 employees. In 2014, the sales revenue has reached RMB21.98 billion Yuan and the brand value of FOTON LOVOL is evaluated to be RMB 26.498 billion by the World Brand Lab.
In China, FOTON LOVOL has been identified as the "National Key High-Tech Enterprise", its engineering and technology research institute is identified as the "Nation-Certified Enterprise Technology Center", and moreover, its leading products have been awarded as "Chinese Famous Brands", "Chinese Famous Trademarks" and "Most Competitive Brand".
FOTON LOVOL is the largest agricultural equipment manufacturer in China and it provides information, technology, products and other sets of agricultural mechanization solutions to customers on the basis of world-level leading technology and services.
The sales of combine harvesters have been ranked 1st for 14 consecutive years in the industry, covering a market share of 70% in China. Large and medium tractors have also been leading the industry in market share for 10 consecutive years. At the same time, it's one of the fastest growing brands in construction machinery industry, available provide users with full range of products of loaders, excavators and rotary drilling rigs.
Technology innovation is the soul of enterprise. To keep up with international standards in R&D abilities, Foton Lovol has established the global R&D system with R&D centers in Europe, Japan, Weifang and Tianjin. Foton Lovol has been introducing the quality resources globally in terms of product, technology and personnel and utilizing the strengths of team, system, culture and management to realize value addition and creation in all links of value chain and keep the core technology up with the international standards.
Based on its leading position in China, Foton Lovol is also active in overseas markets. By now, it has established the business network covering agricultural equipment, construction machinery, vehicle and engine exported to more than 120 countries and regions including Europe, America, Asia Pacific, CIS, Africa and so on with 380 first-class distributors. The export of tractors has been the 1st for ten consecutive years in the field.
Looking into the future, Foton Lovol will focus on China market and keep its leading position. Foton Lovol will transform from a regional company into a global enterprise by building up China as the center of global off-road industry and it is also dedicated to become a machinery and equipment brand known in the world and famous in China.
