Four Column Type Rubber Curing Press

Name: Four Column Type Rubber Curing Press
Brand: china-manufacturer-directory.com
SKU: 698992002
Availability: InStock
Rating: 4.4 (121 reviews)

Price:	US $ 2000-30000/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Colour:	as Customers' Requirements
Advantage:	Without Oil or Dust Leakage
Temperature:	Can Be Adjustment
Type:	General Rubber Machinery
Type Of General Rubber Machinery:	Material Processing Machine
Type Of Tire Machinery:	Rubber Regeneration Machinery
Weight:	50~300 tons
Power:	10~100KW
Voltage:	220V
Using Life:	≥15 Years
Certification:	CE, ISO

Product Description

a.rubber vulcanizing machine

1.this kind machinery has three types of frame type, pillar type, and jaw type. It is economical, advantage of compact structure, high working pressure, high producing efficiency,. Operation is safe and reliable.

2. This series of products have high press in unit area , so that we can ensure the quality .

3.Machine can be equipped with model pulling and pushing device to reduce work strength based on product requirements .Hand control ,electrical control and PLC control is optional.

4.The working layer number can be designed as the request.

5. valcanization process can achieve many procedures for automatic control ,can automatically detect and adjust hot plate rubber machine .

6.This type of machine is control by PLC , valcanization process can achieve many procedures for automatic control ,can automatically detect and adjust hot plate rubber machine.

Technical parameter:

Model		XLB 350X350X2	XLB 400X400X2	XLB 500X500X2	XLB 600X600X2(4)	XLB 750X850X2(4)
Nominal pressure(MN)	0.25		0.50	0.60/0.80	1.00	1.60
Plate size(mm)	350X350		400X400	500X500	600X600	750X850
Plate clearance(mm)	125		125	125	125	125
Working layer number	2		2	2	2(4)	2(4)
Plate unit pressure(Mpa)	2.04		3.13	2.52	2.78	2.51
Piston stroke(mm)	250		250	250	250(500)	250(500)
Motor power(kw)	2.2		2.2	2.2	2.2	3.0

The company owns powerful technical strength, advanced technics, the best design and strict quality guarantee system, which owns a high repution in China rubber machinery industry.

The main products are plate vulcanizing press, open rubber mixing mill, banbury intensive kneader, extruder, rubber and reclaimed rubber machinery, within the (outside) tires complete set of machinery.The products have been sold to more than 20 provinces and cities in China and have been exported to more than 10 countries and areas.All of the products are designed visually by three-dimension CAD design, quickly built module, limited element analysis, analogue action and interfering inspection.The combination of three-dimension CAD system and internet guarantees the synchronization with internatinal advanced technology.The combination of three-dimension CAD and CNC numeral process center realizes the transit from traditional manufacture to modern three-dimension manufacture.At the same time, the company keeps good contact with several universities and research institutes.

The company takes"To live by quality, To develop by reputation, To innovate by science and technology, To keep improving all the time"as managing ideas, and insists on the principle of "Quality is the first, Reputation is the?First, Client is the first" that will provide you the best service.
