Price: | US $ 0.1-0.3/Piece |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 500/Piece |
Pay Type: | L/C,T/T,Paypal |
Products feature:
Description | Unit | Value |
Water absorption | % | <0.25 |
Flexural strength | MPa | >350 |
Surface resistivity (C-96/20/65) | MΩ | >105 |
Volume resistivity(C-96/20/65) | MΩ·m | >104 |
Dielectric lose factor (1MHz) | - | <0.03 |
Heat resistance 220°C 20mm | - | No bubble |
Flammability UL94 (1.6mm) | Class | V-0 |
Solvent resistance | - | No change |
Density | g/cm3 | 1.85-1.95 |
Charpy impact strength | kJ/m2 | >45 |
Size | mm | Customized |
Note: Colors white, yellow, black, light green are available, the specifications above not applicable in black. |
Our processing service:
1.Plastic cool and hot bending fabrication.
2.CNC machining/CNC routing
3.Gluing
4.Thermoforming
5.Silkscreen printing
6.Punching
7.Sandblasting
8.Polishing
9.Drilling
10.Milling
11.Plastic coating processing
12.Plastic parts assembly
FAQ:
How long can I expect to get the sample?
After you pay the sample charge and send us confirmed files .The
sample will be sent to you via express and arrival in 3-15 days.
How can I get a sample to check the quality ?
After price confirmation, you can require for samples to check our quality.
What is your terms of delivery?
We accept EXW,FOB,CIF etc, you can choose the one which is the
most convenient or cost effective for you.
Any goods in stock?
Usually we make goods only after order, most of orders are customized.
Sincerely wait for your inquiry, we will give you the best quality and the most reasonable price for the products .If there is anything we can do for you ,please contact us at any time!
Prod Model: | QRD-035 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: | Customized |
Shape: | as Your Drawing |
Price: | Depends on The Size |
Usage: | Dielectric |
Application: | Switch Baseplate |
Type: | Insulation Sheet |
Chemistry: | Inorganic Insulation |
Material: | Fiberglass |
Thermal Rating: | 220 220 |
Maximum Voltage: | 20KV~100KV |
Brand: | Qrd |
