Product Specifications
Prod Model: |
YVBP |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Model: |
Yvbp-80m1-4 |
Rate Power: |
0.55kw |
Current: |
1.6A |
Rated Torque: |
3.5 N.M |
Speed: |
880 R/Min |
Voltage: |
380V |
Torque Change Range: |
5-50Hz |
Power Change Range: |
50-100Hz |
Weight: |
21kg |
Noise Level: |
73 dB |
Application: |
Power Tools |
Operating Speed: |
Adjust Speed |
Number Of Stator: |
Three-Phase |
Species: |
Explosion-Proof Three-Phase |
Rotor Structure: |
Winding Type |
Casing Protection: |
Closed Type |
Starting Mode: |
Direct on-line Starting |
Brand: |
Kender |
Product Description
1,Rated voltage:220V/415/380/660V
2,Rated Frequency:50HZ/60HZ
3,Protection class:IP55
4,Work system:S1
5,Insulation class:B,F
6,Pole:2-8
7,Rotor:Squirrel cage rotor
8,Flame-proof mark:ExdI, ExdII AT(1-4)ExdII BT(1-4)
9, Frame NO:62-355
Advantage of Frequency Conversion Electric Induction AC Motor
1,Frequency Conversion
2. Speed Regulation
3,One year warranty
4. High protection class
5,High efficiency,Energy saving
6,Long using life
7,Easy installation and maintenance
Application of Frequency Conversion Electric Induction AC Motor
1,Apply for transport machinery
2,Apply for coalmine winch
3,Apply for crusher
4,Apply for water pump
5, Apply for Ventilator Fan
Technical data of Frequency Conversion Electric Induction AC Motor
Model Type | Standard Power | Rated Current | Rated torque | Noise level | Torque change range | Power change range | Weight | Length |
| | | | | | | | |
| (kw) | (A) | (N.M) | dB(A) | | | (KG) | (L) |
YVBP 80M1-4 | 0.55 | 1.6 | 3.5 | 73 | 5-50Hz | 50-100Hz | 21 | 400 |
YVBP80M2-4 | 0.75 | 2.1 | 4.7 | 73 | 5-50Hz | 50-100Hz | 22 | 400 |
YVBP 90S-4 | 1.1 | 2.8 | 7 | 76 | 5-50Hz | 50-100Hz | 26 | 430 |
YVBP 90L-4 | 1.5 | 3.7 | 9.5 | 76 | 5-50Hz | 50-100Hz | 30 | 455 |
YVBP 100L1-4 | 2.2 | 5.1 | 14 | 79 | 5-50Hz | 50-100Hz | 42 | 495 |
YVBP 100L2-4 | 3 | 6.7 | 19 | 79 | 5-50Hz | 50-100Hz | 43 | 495 |
YVBP 112M1-4 | 4 | 8.8 | 25.4 | 80 | 5-50Hz | 50-100Hz | 55 | 515 |
YVBP 132S1-4 | 5.5 | 11.7 | 35 | 86 | 5-50Hz | 50-100Hz | 83 | 597 |
YVBP J132M1-4 | 7.5 | 15.6 | 47.7 | 86 | 5-50Hz | 50-100Hz | 95 | 635 |
About Kender :
1,The company covers an area of 5000 square meters;
2,Modern workshops have advanced production lines and professional knowledge of assembly.
3,Excellent sales team and after-sales service
4,Professional technical team
5,Broad market:Europe(Germany....)America(America,Canada...)
Asian( Korea, Japan...)
Packing
Inspecting spare parts every processing
100% test after each process and final test before packing.
Contact Kender
1,Your client satisfied on the right schedule and quality;
2,You can get good reputation from your market and obtain more orders;
3,Our professional service before and after sale;
4,The reasonable and competitive price;
5,Service is excellent.Any questions from you are welcome and will be replied in 24 hours.
6,Delivery on time
FAQ
Q:What's the voltage of your motor?
220/380V/660
Q:What's the frequency of your motor?
50HZ or 60HZ
Q:What'a the phase of the motor?
Single phase or three phase as your required.
Q:What's the mounting size of your motor?
Design as customer required.
Q: Do you offer OEM service?
A: Yes.
Q: What is your payment term?
A: 50% T/T in advance,50% before delivery. Or irrevocable L/C.
Q: What is your lead time?
A: About 10-45 days after receiving deposit or original L/C.
Q: What certificate do you have?
A: We have CE, ISO9001,CCC ,EX and so on.
