Product Specifications
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Type: |
Cultural Paper |
| Sheet Former Type: |
Cylinder Mould |
| Paper Thickness: |
Normal Specification Paper |
| Certification: |
ISO |
| Condition: |
New |
Product Description
company:
we are a professional paper machine manufacturer,here,you can get the whole production line,we promise you good solution cause that is what we pursue
so welcome to visit and negotiate
Perfect service:
1.technical consultation
2.Plant design
3.installation and test run
4.training engineers and workers
5.good and long time after-sale service
contact & negotiate!!!
The business process
1.send your requirements:raw material,capacity,paper grammage
2.we make the solution to you
3.come visit and negotiate
4.sign contract
5.first payment
6.production
7.pay spare money
8.delivery
9.installation ,training,test run
10.production consultlation
1575mm 10TPD Cultural Paper Making Line
I. Technical parameter
| 1. Raw material | waste paper |
| 2. Output paper | cultural paper |
| 3. Output paper weight | 40-80gm2 |
| 4. Capacity | 10TD |
| 5. Wire width | 1950mm |
| 6. Net paper width | 1600mm |
| 7. Working speed | 90-100mmin |
| 8. Designing speed | 50-150m/min |
| 9. Rail gauge | 2400mm |
| 10. Drive way | Alternating current frequency conversion adjustable speed, sectional drive. |
II. The structure and specifications of main equipment
1. Cylinder part: 1500mm×1950mm×2400mm stainless steel plate cylinder 2 pcs,
400mm×1950mm×2400mm couch roll 2 pcs,
2. Press part: Φ650mm×1950mm×2400mm natural marble roll 2 pcs, Φ600×1950mm×2400mm rubber roll 2 pcs, rubber shore hardness 95ºC±2,
pneumatic pressure device.
3. Dryer part: Φ1500mm×1950mm×2400mm alloy dryer can 6 sets. The first and second are chromeplate dryer cans. It 's equipped with dry felt device, scrapers 6 pcs,
Semi-closed dryer hood 1 set.
4. Calendaring part: three-roll calendar 1 set, and top roll Φ350mm, middle roll Φ300mm, bottom roll Φ400mm.
5. Winding part: equipped with horizontal pneumatic winding machine 1 set. The winding drum is Φ900mm×1950mm×2400mm.
6. Rewinding part: equipped with frame type rewinding machine 1 set.
7. Cutting part: equipped with heavy duty single cutter 1 set.
1575mm 10TPD Cultural Paper Making Line
I. Technical parameter
1. Raw material waste paper
2. Output paper cultural paper
3. Output paper weight 40-80gm2
4. Capacity 10TD
5. Wire width 1950mm
6. Net paper width 1600mm
7. Working speed 90-100mmin
8. Designing speed 50-150m/min
9. Rail gauge 2400mm
10. Drive way Alternating current frequency conversion adjustable speed, sectional drive.
II. The structure and specifications of main equipment
1. Cylinder part: 1500mm×1950mm×2400mm stainless steel plate cylinder 2 pcs,
400mm×1950mm×2400mm couch roll 2 pcs,
2. Press part: 650mm×1950mm×2400mm natural marble roll 2 pcs, 600×1950mm×2400mm rubber roll 2 pcs, rubber shore hardness 95±2,
pneumatic pressure device.
3. Dryer part: 1500mm×1950mm×2400mm alloy dryer can 6 sets. The first and second are chromeplate dryer cans. It 's equipped with dry felt device, scrapers 6 pcs,
Semi-closed dryer hood 1 set.
4. Calendaring part: three-roll calendar 1 set, and top roll 350mm, middle roll 300mm, bottom roll 400mm.
5. Winding part: equipped with horizontal pneumatic winding machine 1 set. The winding drum is 900mm×1950mm×2400mm.
6. Rewinding part: equipped with frame type rewinding machine 1 set.
7. Cutting part: equipped with heavy duty single cutter 1 set.
Our company has over 420 employees. There are five factories in China with the total area of 20, 000m2, it has passed the ISO14001 international authentication
Our products include paper making machines, parts and paper processing machines such as kraft paper machine, tissue paper machine, cultural paper machine, fiber separator, hydrapulper, rewinder, napkin folder, tisue slitter and ao on. They have been exported to more than 8countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying in perfect & advanced technology, sincere service and inexpensive products with high quality, we have won the recognition of international market and clients
Why choose us
Our company gathers a technique team of engineers and experts with over 30 years' experience which helps us be a professionall on all kinds of paper making machines and make us competitive on the market. We focus on quality and customers' need and improve our technology and service continually. We believe our devotion to work will help us to achieve global leadership in providing first-class products and superior quality services to customers around the world
Our advantages
Technical advantage
1. Experiences producing team
2. Advanced technological strength
Product advantage
1. Through the international authentication
2. Same material with most preferential price
3. A lot of varieties for the customer to choose
Service advantages
1. Technical consultation
2. Project evaluation
3. Detailed design of factory
4. Installation and test the whole production line
5. Training engineers and workers
6. Supplying spare parts for long time
