Product Specifications
| Prod Model: |
K71,Q030,Q055,M60,M92,SR2,SR35,N25,N35,N50 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Heat Exchanger Plate: |
Stainless Steel 304, 316L, Titanium, Hastelloy |
| Heat Exchanger Gasket: |
EPDM, NBR, Viton, HNBR |
| Frame Material: |
Ss304, Carbon Steel |
| Style: |
Sealing Strip |
| Shape (for Gasket): |
Grooved Gasket |
| Function: |
Fixed Sealing |
| Application: |
Equipment Seal, Flange Seal, Plate Heat Exchanger |
| Standard: |
Standard |
| Type: |
Metal Rubber Compound Sealing Strip |
| Vulcanization: |
Continuous Vulcanization |
| Usage: |
Doors & Windows |
| Material: |
Rubber |
Product Description
As a professional manufacturer of PHE and related part, we have two types for GASKET. One is clip on, the other is glue type. The design of GASKET is based on several years of practical experience gained from customers' requirements. We have a range of customer-designed GASKET for efficient thermal treatment of liquid and sensitive products.Gasket Material: Rubber, NBR, EPDM;
Plate Material: Stainless steel AISI316L, AISI304, titanium, hastelloy, alloy;
Frame Material: Carbon steel, AISI304;
Application: Evaporator or condenser;
Advantage of 6Z heat exchangers:1. High quality
2. Reasonable price
3. Customer - designed
4. Short delivery time
5. After-sale service
|
Material of Plate |
Suited Liquid Kinds |
|
Stainless Steel (SUS304. 316 Etc) |
Pure Water, Normal Water, Oil for eating, Mineral Oil |
|
Ti, Ti-pd |
Sea Water, Saline Water, Mineral Water |
|
20Cr, 18Ni, 6Mo (254SMO) |
Dilute Sulphuric Acid, Organic Water Solution |
|
Ni |
High-temp and concentration caustic soda |
|
Hastelloy (C276, D205, B2G) |
Concentration Sulphuric Acid, Hydrochloric acid, Phosphoric acid |
|
Material of Gasket |
Operating Temperature ° C |
Suited Liquid Kinds |
|
NBR |
-15~+135° C |
Water, Sea Water, Mineral Oil, Salty Water |
|
EPDM |
-25~+180° C |
Hot Water, Steam, Acid, Caustic |
|
F26 |
-55~+230° C |
Acid, Caustic, Fluid |
|
TPF |
0~+160° C |
Concentrated Acid, Caustic, High-temperature Oil, Steam |
