Advantage:
1.Using import SCR in the main circuit, output current is steady;
2.Strong frame design can reduce the upper and the lower electrode deviate when force;
3.Adopt IC controlled technology, control precision is high, welding is steady, wide application and can used for a long time;
4.Direct force structure, lubricate well, make the electrode move steadily, responds rapidly, increase the spot speed;
5.Using extensively for wide application such as carbon steel, stainless steel and low carbon alloy steel.
| Data/Type | DN-100 |
| Input Voltage(V) | 380 |
| Power frequency(HZ) | 50 |
| Number of power phase(N) | 1 |
| Rated capacity(KVA) | 100 |
| Continuous Loading Rate(%) | 20 |
| Output No-load Voltage(V) | 8.2 |
| Weldment Thicknessmm | Low-carbon Steel | 4+4 |
| Stainless Steel | 2+2 |
| Aluminum | 0.5+0.5 |
| Upper Electrode Operating Frequency Spot(min) | 60 |
| Electrode Arm Length(mm) | 450 |
| Electrode Full Stroke(mm) | 125 |
| Electrode Operating Stroke(mm) | 20 |
| Electrode Maximum Pressure(Kn) | 10 |
| Input Gas Source(Map) | 0.5 |
| Cooling Water Consumption(L/H) | 600 |
