Product Specifications
| Prod Model: |
ARW-2400-2700-18 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Communication Antenna |
| Directionality: |
Omnidirectional Antenna |
| Operating Wavelength: |
Microwave |
| VSWR: |
<1.5 |
| Material: |
Steel Plate |
Product Description
Applications:
2.4GHz UNII/ISM System
WiFi System
Point to Point or Point to Multi-point
Support IEEE802.11A/b/g
Features:
High Gain, Low VSWR
Designed by Dual-band Method
Compact Size, Good AppeARance
Indoor Use, All Weather Operation
Wall Mount Installation
|
Product NARe |
Wall Mount Antenna |
|
Electrical Specifications |
|
Model |
ARW-2400-2700-18 |
|
Frequency Range–MHz |
2400-2483 |
|
Bandwidth-MHz |
|
|
Gain-dBi |
18 |
|
Horizontal BeARwidth -° |
47 |
|
Vertical BeARwidth -° |
47 |
|
F/B ratio-dB |
20 |
|
VSWR |
≤1.5 |
|
Input Impedance -Ω |
50 |
|
PolARization |
Vertical |
|
Maximum Power -W |
100 |
|
Connector |
N Female |
|
Mechanical Specifications |
|
Dimensions-mm |
305×305×30 |
|
Weight-g |
600 |
|
Mounting |
Wall Mount |
