Product Specifications
Prod Model: |
OAT-4113 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Model: |
Digital Duplicator Machine (Oat-4113) |
Processing: |
High-Speed Automatic Digital Scanning |
Original Mode: |
Text/Picture/Text and Picture |
Scanning Resolution: |
300*400 Dpi |
Power Supply: |
AC 200-240V 50Hz |
Main Display: |
English and Chinese |
Print Speed: |
45-130sheets/Min (45, 65, 85, 105, 130) |
Connect Computer: |
USB Interface |
Certification: |
ISO9001:2008 |
Electricity Save: |
Yes |
Color Type: |
Colored |
Type: |
Digital Copier |
Copy Speed: |
High |
Price: |
≥US $750/pcs |
Max Copy Size: |
B4 |
Product Description
The OAT-4113 digital duplicator has high-luminance LCD of 300× 400dpi resolution and is provided with special printing paper, thus enabling you to easily realize high precision, high speed and low cost printing in bulk.
No matter what type of Originals you want to print, the product is furnished with letter mode, photo mode, letter/photo auto-separation mode and can realize simple, quick and reliable operation.
When there is a need for choosing a set of office equipment with simple operation, high efficiency, lost cost and delicate printing effect, OAT-4013 digital printer is certainly an ideal choice of government organs, education systems, businesses, publishers and printing firms that print large quantity of high-grade materials.
Big LCD Display
50-200% zoom
300 * 400dpi resolution
252mm*355mm image area
1000 sheets paper feeding/delivery tray
Optional color drum to perform color printing
The more the printing volume of each master, the cheaper the cost of each copy
Proprietary master technique, ensuring high quality picture expression
Character |
Processing |
High-Speed Automatic Digital Scanning/Fully Automatic, Thermal Screening Duplicator System |
Scanning |
Flat bed scan |
Original Input Type |
Book or sheets and computer input |
Master making |
Digital thermal master making |
Specifications |
Print Area |
Max. 252mm*355mm |
Original Size |
Max. 297mm*420mm
Min. 100mm*148mm |
Image Area |
Legal Drum: 252mm*355mm |
Paper weight |
40g/m 2 -210gm 2 |
Original Mode |
Text/Picture/Text and picture |
Scanning Resolution |
300× 400 dpi |
Time of First Paper Printed |
Approx. 48 Seconds |
Master eject box capacity |
25 sheets |
Master on/out |
Automatically Controlled |
Ink Feeding Mode |
Automatically Controlled |
Density Control |
Lighter, Light, Normal, Dark, Darker |
Tray Volume |
Feeding Tray 1, 000Sheets (70g/m 2 )
Receiving Tray 1, 500 Sheets (70g/m2) |
Control Panel |
LCD |
Weight |
G. W: 113kgs
N. W: 96kgs |
Power Supply |
AC 200-240V 50Hz |
Main Display |
English and Chinese |
Print Speed |
45-130sheets/min (45, 65, 85, 105, 130) |
Zooming Parameters |
7 Selectable Zooming 70%, 81%, 87%, 94%, 100%, 122%, 141%. Free Zooming 50%-200%. |
Printing position adjustment |
Vertical ± 10mm,
Horizontal ± 20mm |
Color printing |
Replace Drum |
Other Functions |
Connect computer |
USB interface |
Original combination |
Yes |
Electricity save |
Yes |
Ink save |
Yes |
Option |
Sorter, code system |
