MAIN TECHNICAL SPECITIFICATION
Model: CBW4000XE
Motor type self excitation, two-stage
AC frequency (Hz) 50/60
Maximum output(KW) 3.5
Rated output(KW) 3
Rated voltage(V) 220
Rated current 13.6
DC output (V/A) 12/8.3
Poles 2
Insulation grade 8
Engine CBW178FA
Type Single-cylinder, 4-Stroke, Air-cooled diesel Welder Engine
Displacement(cc) 296
Speed 3000/3600
Starting mode Electric start or recoil start
Lubricating oil capacity 1.1
Fuel tank capacity (L) 15
Fuel consumption rate 276.1
Fuel diesel
Cooling method forced cooling
Lubricating method forced cooling
Run time(h) 9
Changzhou Changbaowang Machinery Import&Export Co., Ltd., under the stock enterprises. Is located in the Yangtze River Delta. Agricultural machinery production base - Changzhou City, Jiangsu Province. The company has invested more than 50 million and currently employs nearly 300 people (including 12 senior technicians, engineers and technicians 28). The company has advanced automatic production lines, will work closely with relevant research institutions. A few years of production of agricultural machinery of the essence, carefully selecting and careful manufacture, diesel engine, tractor, rotary tiller and other products. Demonstrated by the state authority for trustworthy products, products are sold throughout the country, exported to Africa, South America, Southeast Asia and other regions.
