Product Specifications
| Prod Model: |
EL63D05IG3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wavelength: |
635nm |
| Lifetime: |
>10, 000hrs |
| Delivery Time: |
10-20day Depending on The Qty |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1, Industrial level quality
2, high stability
3, high reliability
4, low consumption
5, FDA ISO Certificate
Industrial Laser Diode Modules
Elite Industrial Laser Diode Modules use high quality laser diode with special designed collimating lens and high stable driven circuit (APC). The characteristics are high reliability, long life span (>10000hrs), and high stability. It's mainly applied in all kinds of industrial instruments and equipments, field detecting, surveying instruments, military instruments and equipments; Gun laser sight, medical apparatus, laser appliance and various of laser apparatus, etc.
Key Feature
1. High quality
2. High Stability
3. High reliability
4. APC driving circuit
5. Low cost
6. Long Life
Application:
Industrial Instruments and Equipments
Wild Explore Instruments
Military Instruments and Equipments
Medical Instruments
Surveying Instruments
Bar Scan
Notes:
1) Part of the laser module could be worked at 60-70° C
2) Power Stability was defined as the power output shift at the operating voltage or temperature changing process
3) Operating Voltage also could be 9 ~12VDC
4) High power output red laser module have 110VAC or 220VAC power adapter
Specifications
Model EL63D05IG3
Aperture 6.0mm
Output Power <3.2mW
Divergence(mrad) <0.3
Beam Size 4*8mm (@10m)
Lens Optical Glass
Dimension Customized
Items |
Specifications |
|
Spectral Range |
Violet |
Blue |
Red |
Infrared |
|
Wavelength |
405nm |
450nm |
635nm |
650nm |
780nm |
808nm |
830nm |
850nm |
980nm |
|
LD power(mW) |
5- 50 |
5-60 |
5~180 |
5~150 |
5~200 |
50~5000 |
5-100 |
5~100 |
20~5000 |
|
Operating Current |
25~5000mA |
|
Input Voltage |
2.6~5.5VDC |
|
Operating Temp. |
-10°C ~ 50°C |
|
Storage Temp. |
-40°C ~ 80°C |
Power Stability |
> 98% (@2.7 ~ 5.5VDC) |
|
> 95% (@-10°C ~ 50°C) |
MTTF |
>10000 Hrs. |
|
Circuit Protection |
Static, Surge, and Reverse Polarity Protected |
|
Case Material |
Brass or Aluminum |
|
Beam Pattern |
Dot, Line ,Cross |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
