| Price: | US $ 20.1-48.5/Square Meter |
|---|---|
| Trade Terms: | FOB,CIF |
| Min Order: | 2000/Square Meter |
| Pay Type: | L/C,T/T |
| Prod Model: | W-SPZ |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: | 1mx2m |
| Zinc Coated: | 40-60G/M2 |
| Brand: | Heping |
| Type: | Sound Barriers |
| Acoustic Panel Type: | Metal Acoustic Panels |
| Wool Acoustic Panel Type: | Groove Wooden Acoustic Panels |
| Eco-Friendly: | E1 |
| Fireproof Grade: | B1 |
| Surface Finishing: | Painting |
| Certification: | ISO |
| Color: | Gray |
Specifications
1Panel thickness: 80mm, 100mm,120mm
2Size: 2500x500x80mm, 2500x500x100mm, etc
3Metal plate thickness: 0.5-1.2mm
noise barriers
. Material: outer: alluminium, inner:glass fiber.
2. Type: shutter, transparent, perforation.
3. Usage: railway, highway, road, downtown, building and so on.
The structure of sound barrier:
the internal fillings are water-repellent E-fiber glass or water-proof noise absorption film and centrifugal compound glass fiber; the back plate is made of GFRP extruding materials.
4.Major advantages:
1. Selected materials and innovative structure, non-corrosion after exposing in the environment;
2. High strength, and non-deforming;
3. Light weight , can reduce the acoustic shield base and the strength of column, and bring convenience to site installation;
4. Ideal landscape effects, different models that conform to the environment can be designed according to the customer's needs;
5. Excellent sound absorption effects, can satisfy the needs of various noise sensitivity;
6. Convenient maintenance, non-fading, easy washing and change after damage.
PC/PMMA Sheet | |||
Panel Height | Height | Sheet Thickness | Light transmittance |
0.5m 1.0m 1.5m | 2.0m 2.5m 3.0m 4.0m | 80mm 100mm | 80%min |
Remark: 1. Length: Max4.0m; 2. Other size on quest | |||
Metal Sheet | ||||
Panel Height | Panel Length | Sheet Thickness | Sheet thickness | Panel type |
0.5m 1.0m | 2.0m 2.5m 3.0m 4.0m | 80mm 100mm | 1.0-1.5mm | Shutter or perforated |
Remark: 1. Length: Max4.0m; 2. Other size on quest | ||||
Sound Barriers | |||
Total Height | Length | RW | NRC |
3.0m as standard | 2.0m 2.5m 3.0m 4.0m | 30dBmin | 0.84min |
