Baling Application
cardboard, paper, PET bottles, PP/HDPE containers, textile waste, film, packing material, fiber,disposable plastic tableware, etc
Video
youtu.be/dcDa9GYWINY
http://www.youtube.com/watch?v=J2zPjAZ2Q2U
Webpage
http://www.sinobaler.com/baler/manual-tie-horizontal-baler/
Photos
Design Features
- Automatic Bale Ejecting System
enables labor-free bale ejecting
- Close-end Design
ensures dense balesespecially for hollow products
- Bale Exit Island
allows bale to be easily removed with forklift
- PLC Control System
automates the operation and promotes accuracy
- Electric Controlled
for easy operation, simply by operating on buttons and switches to fulfill platen moving and bale ejecting
- Hydraulic Lifting Chamber Door
for automatically lifting up to let the bales come out, which promotes operation efficiency and increase output
- Horizontal Cutter on Feeding Mouth
for cutting off the excessive material to prevent it from being stuck at the feeding mouth
- Automatic Feeding Conveyor is Optional
forcontinuous feeding material, and with the help of sensors and PLC, conveyor will automatically start or stop when the material below or above certain position on hopper. This enhances feeding speed and maximize throughput
Specifications
| Model | SHB1-400 | SHB1-600 | SHB1-800 | SHB1-1000 | SHB1-1200 |
| Nominal Force | 40ton | 60ton | 80ton | 100ton | 120ton |
| Bale Size (L*W*H) | 1100*750*750mm | 1100*750*750mm | 1200*1100*750mm | 1400*1100*750mm | 1500*1100*1100mm |
| Bale Weight (OCC) | 150-250kg | 200-300kg | 300-400kg | 400-550kg |
700-850kg
|
| Motor | 15kw | 18.5kw | 22kw | 22kw | 30kw |
| Machine Weight | 3500kg | 4700kg | 6500kg | 7500kg | 10000kg |
| Machine Dimension | 6450*1250*1950mm | 6750*1250*2050mm | 6880*1550*2050mm | 7280*1550*2050mm | 7550*1550*2110mm |
Package
Customers
Q&A
Manufacturing Lead Time: 45 days after receiving deposit
Warranty: We provide 13 months' warranty starting from shipping date. Within the warranty period, in the event of any malfunction caused by the quality of the baler, we will provide you corresponding parts for replacement free of charge. Wearing parts are excluded from this warranty. Every machine has been commissioned, debugged and passed our in-house inspection before leaving our factory.
After Sales Service: Technical support is available for the entire lifespan of the machine, if you need any assistance, we will provide solutions via various means like email, PPT presentation, phone call, video conference etc. within 24hours.
Sinobaler is a leading supplier of baling machines in China. We provide customers individual baling solutions for all types of waste material covering waste paper, plastic, rubber, textile, wood scrap, hay, metal drum, urban waste, etc. Cost-effective, highly-efficient, durable and user-friendly size reduction equipment is what we deliver. Our manufacturing covers the full range of vertical and horizontal balers from small size to large size, and we can also customize machines to suit a client's specific need and possible space restrictions.
Machine quality is considered as priority by Sinobaler Team. From raw material procurement to finish-machine inspection, from welding to assembling, from mechanical structure to hydraulic pack, all is processed under strict procedures and supervision. Our machines follow European standard, and all our balers passed CE certificate. A great deal of our time is devoted to the quality control system, ensuring everything baler delivered will satisfy the client both in its value and quality, ensuring years of trouble-free operation and minimal maintenance expense.
So far our baling machines are sold to over 80 countries around the world, and we have built distributorship in 8 countries. Our aftersales engineers are travelling around the world all year round to provide our clients with all types of technical support including machine erection, commissioning, consultation, operation training, maintenance, etc.
Our goal is to become a leading world-class recycling machinery manufacturer, making SINOBALER the first choice when recycling machinery is required.
