Jinan ATC cnc wood machinery
1. Perfect Model for Material from Sheet to Large Blocks of Foam for Mold Making
2. Heavy Duty, Thicken Steel Tube Frame with Quenching Treatment
3. World Famous Servo motor, Spindle, Driver
4. Advanced Controller Syntec Controller with Ethernet interface
Superiority of ATC CNC Router:
OMNI 1530ATC CNC router, adopting CATC-T8 carrousel Tool technology, will take the shortest path between any two tools, allowing the quickest change times possible. The tool-changer eliminates the need for the operator to stop the machine to change tools manually, allowing the program to continue uninterrupted.
1) Support 8 tools ATC system, tool magazine is with carrousel/umbrella form
2)Automatically senses the wrong tool in the tool magazine, to avoid no operation and tool collision.
3)Intelligent sensor system, automatically sense whether the tool in the spindle, can avoid the collision and faulty operation.
4) Automatically senses whether the pressure could meet the requirements, and is with the function of lower pressure alarming.
5) The systemautomatically remember the location of the tool and tool length. It only need to re-measure the tool length for every time tool changing.
Application:
1. Woodworking industry: three-dimensional wave board processing, cabinet door,
craft wooden door, folding screen, process window milling shape carved
furniture products.
2. Advertising industry: advertising signs, PVC board, chevron board, double color boards, logo making, acrylic cutting, plastic molding, characters, crystal cutting,
plate making, cutting PVC board, acrylic, LED/neon trough, the hole shape
literally cut, blister light boxes mould
3. Arts and crafts industry: in the wood, bamboo, marble, organic board, double
color boards, such as material for a variety of exquisite design and text on the
sculpture.
If you have specific requirement for woodworking machinery CNC router machine, customization is available.
Packaging & Shipping
OMNI offer double film packing and freefumigation wooden case with steel tubes for protecting the machine very well on the sea.
Qingdao, Tianjin, Shanghai or other sea port are acceptable.
About us
OMNI is the leading manufacturer of cnc router ( 3 axis, 4 axis and 5 axis cnc router), laser machine, cnc plasma cutting machine in China. OMNI supply machines to a wide variety of manufacturing sectors including aerospace, automotive, marine, recreational vehicles, 3D sculpture, concept models, pattern making, formed plastics and wood working.
The OMNI Quality Assurance program pays close attention to every detail in order to guarantee that each machine is of the highest quality and standard of reliability for any CNC router, laser machine, cnc plasma cutting machine available on the market.
OMNI team make the utmost efforts to meet customer needs and design bright future, bearing in mind that only constant
technology development and a technology driven company can offer reliability and trust to customers.
Model | 1530ATC |
| Working Zone: (X Y Z) | 1500×3000×300mm |
| Table Size (W×L) | 1700×3450mm |
| Resolution | <0.003mm |
| Cutting Accuracy | ±0.03/300mm |
| Repositioning Accuracy | ±0.01mm |
| Axis Drive System (X Y ) | Rack and pinion drive/ Hiwin rail linear bearing |
| Drive Type | Servo motor |
| Spindle | 9kw Italy HSD aircooling spindle optional |
| Max. Working speed | 30,000mm/min |
| Collets Type | 3.175mm/ 4mm/ 6mm/8mm |
| Command Code | G code |
