Ultra Lightweight / High strength ceramsite/aggregate
Basic Info:
Model NO: UL/HS
Shape: granular
Packing:1 Cubic meter/Bag
Grain Size: 0.1mm~1 mm, 1 mm~2 mm, 2mm~8mm , 8mm~16mm
Origin: Beijing, China
Export Markets: Global
Additional Info
Color: Grey, Black
Product description:
This product is mainly made of coal gangue, after the process of granulation, then sintering in kiln we get the material which has the functions of sound absorption and thermal insulation.
Our ceramsites are usually divided into two classes: ultra lightweight ceramsite(UL) and high strength ceramsite(HS). In UL products , each grain contains millions of pores which is the main reason the grain has the lowest density and thermal property. In HS product, in each bulk density grade , we pursue the compressive strength as high as possible
Product application:
1. Filling materials
2. Sound absorb panels and blocks mainly used by UL ceramsite
3. Thermal insulation panels and blocks
4. Lightweight concrete
| items | UL | HS |
| Grain Size(mm) | 0.1~16 | 0.1~16 |
| Loose Bulk Density, Kg/m3 | 140~500 | 500~900 |
| Compressive Strength, MPa | 0.8~4.5 | 5.0~18 |
| Water Absorption by Mass, % | 25~35 | 7~20 |
| Water Absorption by Volume, % | 10~25 | 5~15 |
| PH Value | 7~12 |
| Bulk density of Lightweight Concrete with ceramsite, Kg/m3 | 270~1400 | 1100~1950 |
| Compressive Strength of Lightweight Concrete with ceramsite, MPa | 0.5~25 | 20~70 |
Time has seen the rapid growth of Beijing JGHC tech, Ltd with a proven reputation in supplying new green damp proof, waterproofing material together with good technical service and support since 1997. Beijing JGHC tech headquarters at Changping District, Beijing, with two factories and many product lines. Beijing JGHC tech owns three subsidiary companies, Beijing KTHY Antisepsis Company, Beijing ZMLH Paint Company and Beijing JGHC Water Proof Company.
Beijing JGHC tech has been engaged in the research, manufacture and marketing of new green materials, covering special grouts, water proof materials, inorganic heat-insulation material, light weight concrete, RPC concrete etc^ We have been focusing on the I&D of new products, collaborating with the design institute of railways and Tsinghua University, high performance precast grout is born; collaborating with the scientific research institute of railways, new excellent bridge(high-speed railway bridge, 350km/h) waterproofing materials is born; collaborating with plenty of universities and design institutes, our new green products are widely used in high-speed railways, Municipal road engineering and civil engineering.
As a member of China Concrete & Cement Products Association, China Anticorrosion Technology Association, China Water-proof Association, Beijing Road Association, Beijing Chemical Building Materials Association, Beijing JGHC tech provided a range of bridge waterproofing, structural waterproofing, and basement waterproofing solutions with new and innovative products. We also participated in setting standards, such as< Technical Standard of 350km/h Passenger Railway >< Technical Standard of Post-tensioned prestressed duct Grouting>, .
Beijing JGHC tech has passed the ISO9001 Quality System Authentication, ISO14001 Environmental System Authentication and ISO28001 Career Health System Authentication. Whether you are a main contractor, developer, property owner or distributor, we have a dedicated team of technical managers that are available for free technical advice. We are devoted to supplying our valued clients with the simple, economical, green and effective waterproofing systems.
Please contact us for further information.
