Product Specifications
Product Description
IFR18065125F10C is a high power type lithium iron phosphate battery (battery cell), can be continuous 10C discharge, maximum 15C pulse discharge can be continuous 5C charge. Apply to electric vehicles, hybrid electric vehicles, launch power, electric motorcycles, electric bicycles, and other needs of high-current fast charge and discharge of the occasion. Rated battery capacity is 10Ah, the application of environmental temperature range of -20º C ~70º C.
| Parameter | Specification |
| nominal voltage(V) | 3.2V |
| Nominal Capacity(mAh) | 10Ah |
| Minimum Capacity(mAh) | 10Ah |
| internal resistanc(1kHzAC) | ≤3 mΩ |
| Weight(g) | 260g±2g |
| Size(mm)Thickness * Weight * Height | 18mm*65mm*125mm |
| Standard Charger mode | Constant current 1/2C charge to 3.6V, change to constant voltage 3.6VCurrent reach to C/10 |
| Maximum charge current | 50A (10C) |
| Continuous discharge current | 100A (30C) |
| Maximum peak discharge current | 150A (45C) |
| Discharge termination voltage | 2.0V |
| Cycle life(1C,100%DOD) | ≥1500 times |
| Ambient temperature | Charge: 0~60ºC |
| Discharge: -30~75ºC |
| storage: -40~70ºC |
Creavigo Battery Company is a high technology enterprise, concentrated on technology developing, product-manufacturing and saling. The main product is Lithium iron phosphate lithium ion battery, lithium cobalt lithium battery, polymer lithium ion battery, lithium-manganese dioxide primary battery, lithium-thionyl chloride primary battery and appropriable adapters and charger for lithium ion rechargeable battery. These batteries are suitable for electric bicycles, electric automobiles, power tools, industrial miner's lamp, electric toy, communication UPS. They are used for industry, military, daily living and other various fields. With excellent specialized engineer, we can give the best solution for mobile power.
