Induction Melting Furnace/Medium Frequency Melting Furnace
| Price: |
US $ 1-100000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
T/T,Money Gram,Western Union |
Induction Melting Furnace/Medium Frequency Melting Furnace
Overview and Uses "IF furnace" - also known as the "medium frequency coreless induction furnace"; apply to iron and steel, copper, Ceruse,aluminum, zinc, nickel, gold and silver and other metal melting, heating, insulation, and forging, sintering, hot rolling, bending forming pre-heat treatment. Is mainly used in melting foundry industry.Equipment Main Features 1,Using a zero-voltage scanning soft-start mode, in any case may at any time to start or stop, will not have impact on power supply.2 ,Rapid melting, the production cost is low; pollution is small, comply with environmental requirements;3,A direct effect from the cold furnace melting. Dissolved material will be fully dumped clean. Molten material easy to replace.4,Power adjustment flexibility. Be able to continuously smooth adjustment. Temperature uniformity can be easily controlled. Oxidation burning less. Metal components evenly.5 ,Furnace shell using cast aluminum or steel structure, small footprint; furnace flip dump convenience, according to the need to use electric, manual, hydraulic tilting furnace and other means.6,Designed to automatically adjust angle of inverter circuit that can automatically adjust the load impedance match, without adjustment of capacitance compensation and always run the equipment in good working condition; power supply system diagnostic error function, easy maintenance.
| GY-SCR500KW MELTING 500KG IRON |
|
| MF Melting furnace | Range of molten iron capacity | Ton | 0.5 |
| Max working temperature | C | 1650 |
| Melting rate | ton/h | 0.5~0.6T |
| Cooling water | R ate of flow | ton/h | 50 |
| Pressure | Mpa | 0.2 |
| water inflow temperature | C | >40 |
| Temperature rise | C | >20 |
| Induction heater voltage | V | 380 |
| Induction inner diameter | mm | 560 |
| Induction heater total height | mm | 750 |
| Turndown method | mechanical drive |
| MF Induction heating machine | Range of power | kw | 500 |
| Incoming line voltage | V | 380 |
| Max incoming line current | A | 800 |
| rectifier pulse number | pulse | 6 |
| cooling water | rate of flow | ton/h | 50 |
| pressure | Mpa | 0.1 |
| water inflow temperature | C | > 35 |
| Temperature rise | C | > 15 |
| MF voltage | V | 750 |
| MF frequency | HZ | 1000 |
| Prod Model: |
GY-SCR300KW |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Place Style: |
Horizontal |
| Manufacturing Level: |
a |
| Media: |
Induction Heating |
| Burning Style: |
Induction Heating |
| Pressure: |
High Pressure |
| Water Circulation: |
Natural Circulation |
| Gas Flow Type: |
Natural |
Founded in 2000, Dongguan Guangyuan Inverter Electronic Equipment Factory is a private high-tech factory. Our factory is located in Wanjiang District of Dongguan City in Zhujiang Delta, with convenient transportation near No. 107 national highway and Guangshen speedway.
We have established an R&D system. It is supported by advanced engineers and professional workers, who are especially engaged in researching and developing the machinery of middle or high frequency induction heating and high frequency inverter electrolysis and galvanization power supply. Since we owned strong technique development capability, our factory has been insisting on producing new product and new craftwork to assure our leading position on technique in this field.
Under the effort of several years, our factory has produced series of high quality products in various categories. We can also exclusively produce these products on your requirement to meet you need. Our middle or high frequency induction heating equipment is produced for special voltage condition of some countries. For instance, there is single-phase 110V, three-phase 220V induction heating equipment for America and Japan and three-phase 415V, 440V induction heating equipment for such southwestern Asia countries as Malay and Thailand.
Our factory has a wholesome distribution network. Our products are delivered to America, Europe and southwestern Asia areas. We also built up a lot of offices to provide prompt and quick service to our consumers.
At the beginning of our foundation, we advocated "work with honest and credit, service for ever". This slogan has deeply footed in the culture of our factory, becoming the soul of development and management. During the process of development, it is firmly believed that a wonderful after-sale service is the base stone for a company' S existing. Therefore, our factory takes the thought of "creating values for costumers" as the core of our managing strategies.
Chinese companies are facing the competition and challenge from the whole globe. Our factory will use advanced technology to provide better after-sale service and to find a proper position in the international market. We will hold the spirit of more professional, advanced and perseverant to pursue the wide application of our products in the market. We will also pursue the co-development and advancement with our suppliers and consumers relying on professional technology and good cooperation efforts.
