Product Specifications
| Prod Model: |
IMAG |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sensor: |
Tube/Flange |
| Type: |
Electromagnetic Flow Meter |
| Accuracy: |
?à0.2-0.5% |
| Measuring Media: |
Liquid |
| Principle: |
Impulse-type |
| Measuring Principle: |
Electrical Principles |
| Size: |
Dn50-Dn500mm |
Product Description
With this measurement technique it is possible to reach a standard precision of 0.5% accuracy referred to the measured value with the possibility of a 0.2% accuracy. The calibration of the unit is carried out individually by an internationally certified rig according to the European Codes. The certificate of calibration is an integral part of the instrument supply and has international validity. The wet calibration rig has an accuracy better than 99.97%. The calibration rig complies with the requirements NTC ISO IEC 17025 and the calibration procedures are carried out according to the European EN-45001 Code. To measure volumetric for conductive liquids and pulps
Pipe dimension range DN50-DN500
Measure range < 0, 2m3/h-30000m3/h
Fluid conductivity 5μS/cm
Sensor material SS321
Lining materials PTFE: DN50 - DN1000
Housing material epoxy printing aluminum
Electrodes materials SS316; Hastelloy C; Titanium; Tantalum
Remote version temp. Rubber 80 C; PTFE 150 C
Compact version operating temp. 70 C
Accuracy 2% standard.;
Repeatability 0, 1%
Analog output 4- 20mA; Max. Load 750Ω
Communication protocol MODBUS RTU (opt. ); HART (opt. )
Digital output 0- 5000Hz Pulse output 24Vdc pull-up
Power supply 85-265Vac o 24Vdc Consumption 6W
Protection remote version IP67/IP68 only pipe (opt. )
Display backlit LCD; Forward and reverse flow rate direct, reverse and net total
SGM SHA has manufactured instruments for the measurement and control in industrial processes and in the integrated water cycle. SGM SHA offers instruments for measuring flow, pressure, level, field communication and complete automation solutions.
Our portfolio consists of a wide range of products, designed to meet process requirements with continual Product development to meet changing market requirements.
The continuous development and research of new technologies to improve and expand our range of products Is an integral part of our business.
To complete our strategy we have established some important presences in developing markets in order to Increase our global penetration into every country of the world.
