1 The key parts adopt famous brand are imported, or made of high-strength and high quality stainless with thermal treatment and improve the reliability and durability of the sealant-spreading machine.
2 The agent system adopt two filter system, and improve the mixing uniformity of two components. The system is equipped with high pressure pipe line safety protection device and make operation and use more safe.
3 this curing agent system is fully closed and prevent the air from exposing to agent and get solidified.
4 the high pressure valve of basic material, curing agent pump(namely A and B glue pump) and proportional pump adopt leakage-free special alloy1 The key parts adopt famous brand are imported, or made of high-strength and high quality stainless with thermal treatment and improve the reliability and durability of the sealant-spreading machine.
6 the rubber mixing system adopt international popular static mixer reciprocating belt, and make the mix more evenly.
Main technicial parameter
|
Mixing proportion |
6:1-14:1
|
|
Basic material barrel |
55 gallon (220L) |
|
Curing agent barrel |
5 gallon (20L)
|
|
Max air consumption |
1m^3/min
|
|
Pressure ratio between air and glue |
50:1 |
|
Max squeeze pressure |
29Mpa
|
|
Gas supplying pressure |
0.8Mpa 0.5-0.8Mpa
|
|
Dimension |
1100*9500*1630mm |
|
Total weight |
650kg
|
