Product Specifications
| Prod Model: |
JQX-40F 2Z |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Specifications
JQX-40F 2Z 8PIN 40A power relay
Coil Voltage: DC: 5~ 220V; AC: 6~ 240V
Contact capacity: 40A 250VAC/30VDC
Accept OEM services
CE
JQX-40F 2Z 8PIN 40A power relay
Technical Data:
Contact form: 2Z, 2H, 2D
Contact material: Silver alloy
Contact capacity: 40A 250VAC/30VDC
Coil voltage: DC 5~ 220V; AC 6~240V
Coil power: DC≤ 2.0W; AC≤ 3.2VA
Nominal voltage: 6VDC, 12VDC, 24VDC, 48VDC, 60VDC, 110VDC
Nominal voltage: 6VAC, 12VAC, 24VAC, 48VAC, 110VAC, 120VAC, 220VAC, 240VAC
Contact resistance: ≤ 1000mΩ (1A 6VDC)
Nominal coil power: DC 2.0W; AC 2.5VA
Operation time: 25ms/25ms
Electrical life: 105
Mechanical life: 106
Dielectric strength: Between open contacts: 2500v 1min; Between coil and contacts: 1200v 1min
Operation ambient: -40~+55° c
Zhejiang Zhongji Technology Co., Ltd was established in 1991, with advanced technology, our company is equipped with high standard production lines and a stable technical staff, management team for production and examination.
We have more than 100 series and 1, 000 different kinds of relay specifications, and mainly manufacturer all types of electromagnetic relay, PCB relay, auto relay, high power relay, time relay, counting relay, microcomputer control switch, floatless relay, electromotor protection relay, power-saving control switch, solid state relay, static-stated electric relay, gas relay, the relay bases and so on.
The products of our company have been approved by CE, ISO9001, and the China Compulsory Certification (CCC).All of the products have been listed in quality control system in the China Product Quality Association ( CPQA) "21315".We have established many sales branch offices in the domestic market, and the products are well sold and highly praised in more than 30 provinces, cities and municipalities, and as far away in Europe, America, Southeast Asia, Middle East and Africa, etc.
Zhejiang Zhongji Technology Co., Ltd.With advanced technology, superior quality, reasonable price, good reputation, warm and thoughtful service, provides products to customers' satisfaction.We are willing to sincerely cooperation, create brilliance!
