Xiuyan Precision Instrument Factory >> Krohne Electromagnetic Flow Meter (Optiflux2000 IFC300)

Krohne Electromagnetic Flow Meter (Optiflux2000 IFC300)

Krohne Electromagnetic Flow Meter (Optiflux2000 IFC300)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T,Paypal,Western Union

Product Specifications

Prod Model: Optiflux2000 IFC300
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pipe Size: Dn15~Dn6000
Temperature: 180Degr C
Medium: Conductive Fluid
Sensor: Tube/Flange
Type: Electromagnetic Flow Meter
Accuracy: ?à0.2-0.5%
Measuring Media: Liquid
Measuring Principle: Electrical Principles

Product Description

1. Krohne Electromagnetic flow meter
2. Accuracy: 0.3%
3. Measuring fluid: Conductive fluid
4. Protection grad: IP68, IP65
5. Powered supply: 24VDC or 220VAC
6. IFC100 or IFC300



                                       The Specifications of  KROHNE Electromagnetic Flow meter
Measuring fluid Conductive fluid
Accuracy 0.3%
Repeatability 0.15%, 0.25%
Temperature range of fluid -25---180 C
Rated pressure DN25--DN150: 4.0Mpa                    DN200--DN1000: 1.0Mpa
DN1100--DN2000: 0.6Mpa             DN2200--DN3200 0.25Mpa
Flow rate range of media 0.3---12m/s
Conductivity   ≥ 5μ   s/m
Electrode material 316SS, Hastelloy alloy B, Hastelloy alloy C, titanium, platinum dissolution, tungsten carbide, etc.
Number ofelectrode 4 eletrodes (≤ DN500), 6 eletrodes(≤ DN600)
Lining materials Chloroprene rubber, PTFE F4, FEP copolymer F46, polyurethane rubber and so on
Flange material of bulk 304SS, 20# carbon steel and other materials (special orders)
Installation forms Holder-style (≤ DN300), flange connected (≤ DN350)
Protection grade IP66, IP68
Power supply of converter 220V± 20%, 60 HZ/ 24VDC (opional frome the two )
Signal output Standard: pulse, and 4--20mA. Hart protocol and MODERBUS protocol are optional.
Structural form Integrative type  and splite type(with 5m standard cables )
Power consumption 0.65W
Working environment Environmental temperature: - 25---60oC, humidity: 0.5%--90%
Disply interface of converter LCD and operation interfaces entirely in English that are able to display instantaneous flow, cumulative flow, and multiple flow units can be selected.
Xiuyan precision instrument factory was founded in 1958 October incorporated the collective enterprises. Company is located in "city of jade " -- Xiuyan, picturesque scenery, pleasant environment, convenient transportation.
Enterprise covers an area of 12000 square meters, construction area of 3000 square meters, the registered capital of 1260000 Yuan, the existing staff of 86 people, including 16 technical staff, management staff of 10 people, technical secondary school or above the staff accounted for the total number of employees 78%. Company has strong technical strength, perfect technology, scientific management, enterprises manufacture the main products include Electromagnetic flowmeter, Target flowmeter, Ultrasonic flowmeter, Ultrasonic level meter, Magnetic level meter, Turbine flowmeter, Vortex flowmeter, ect. Enterprise product marketing the whole country, has been used in petroleum, chemical, power, papermaking, brewing, pharmaceutical ect. field of the automatic control system of industrial processes, especially in the petroleum, chemical industry to create own brand. Enterprises has actively expanded the overseas market, has a variety of instruments are exported to Malaysia, Italy, Australia, Zambia, Turkey, America, Brazil, and other countries. At present, the enterprise has passed ISO9001--2000 international quality system certification, report to the Liaoning provincial Science and Technology Agency awarded the High-tech Enterprises. Company for three consecutive years was awarded the "Civilized Unit" title by the Anshan municipal Party committee and municipal government.
Since the company was founded more than 40 years, the joint efforts of leaders and staff, base on the entrepreneurial spirit of " rigorous, pragmatic, efficient, and trustworthy ", adhere to the " quality of products, service first for the customer ", the pursuit of continuous innovation and development, to let the user rest assured, comfortable, happy.
