Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Time: |
10-20day Depending on The Qty |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1, High quality industrial laser diode
2, APC driving circuit
3, Low cost
4, High reliability
5, Long Life
Industrial Laser Modules
1, High quality industrial laser diode
2, APC driving circuit
3, Low cost
4, High reliability
5, Long Life
Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments
Notes:
1) Part of the laser module could be worked at 60-70° C
2) Power Stability was defined as the power output shift at the operating voltage or temperature changing process
3) Operating Voltage also could be 9 ~12VDC
4) High power output red laser module have 110VAC or 220VAC power adapter
Industrial laser diode module, high stability, high reliability, low consumption and mini size
Including green, red & infrared (532nm, 635nm, 650nm, 780nm, 808nm, 830nm, 850nm, 980nm). DOT, line & cross laser module.
Laser Diode Collimators is used in many scientific research field and some industrial production. Laser is better collimation power. Semiconductor Laser Diode Collimators is better than laser modulation with its small dimensions, high collimation (Divergence < 0.1mrad). Our company's design and product for Laser Diode Collimators is specially served for various scientific research and industrial production.
Specifications |
|
Spectral Range |
Red |
Infrared |
Wavelength(nm) |
635 |
650 |
780 |
808 |
850 |
980 |
Output power(nW) |
5~40 |
5~150 |
5~150 |
100~30000 |
5~100 |
50~7000 |
Operating current(mA) |
25(min)~5000(max) |
DC Input Voltage (V) |
2.6~5.5 |
Operating Temperature( Deg.C ) |
From -10 to 50 |
Storage Temperature
( Deg. C) |
From -40 to 80 |
Power Stability via Operating Voltage |
>95% ( @2.7~5.5VDC) |
Power Stability via Operating Temperature |
>90% (@-10°C~50°C) |
MTTF (Hrs) |
10000 |
Circuit Protection |
Static, Surge, and Reverse Polarity Protected |
Case Material |
Brass or Aluminum |
Output Beam |
Dot, Line & Cross |
Dot |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
