Product Specifications
| Prod Model: |
AZJ-8850C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diameter Of Plant Roller: |
120-300mm |
| Printing Speed: |
10-120m/Min |
| Version Accuracy: |
0.15mm |
| Max Width Of Base Material: |
850mm-1200mm |
| Structure: |
Platen Press |
| Style: |
Screen-process Printing Press |
| Type: |
Rotary Screen Printing Machine |
| Print Interface: |
USB2.0 |
| System Supported: |
Windows2000 |
| Color & Page: |
Eight Color |
Product Description
Latest Automatic Rotogravure Printing Machinery
Specifications:
1. The whole machine is fixed by permutation composition, according to the customers' requirement the printing color unit can be increased or decreased as well as the cover printing mechanism can be added.
2. The mainframe adopts vector frequency speed controller, The whole machine adopts threes-motor constant-tension force control system.
3. Each unit of computer flashed system is controlled by separating microprocessor. It can adjust the flashed deviation quickly and precisely.
4. With display of flashed deviation, correcting for system comprehensive deviation as well as super-different slamming function.
5. Double photo-electricity checking; Improve the whole checking and adjustment speed.
6. The winding and the winding traction adopt vector frequency motor and moment motor controller.
7. Wing is adopted with frequency motor with magnetic powder clutch to wind.
8. The printing pressure cylinders, discharging traction pressure cylinders and winding traction pressure cylinders adopt pneumatic controller.
Packing
|
Type |
AZJ-8850C |
AZJ-81050C |
AZJ-81250C |
|
Effective printing width |
800mm |
1000mm |
1200mm |
|
Max width of base material |
850mm |
1050mm |
1250mm |
|
Printing speed |
10-120m/min |
10-120m/min |
10-120m/min |
|
Speed of machine |
150m/min |
150m/min |
150m/min |
|
Max diamention of rewind |
600mm |
600mm |
600mm |
|
Inside diamention of roll core of base material |
76mm |
76mm |
76mm |
|
Diameter of plant roller |
120-300mm |
120-300mm |
120-300mm |
|
Version Accuracy |
±0.15mm |
±0.15mm |
±0.15mm |
|
Heating Power of oven |
78KW |
86KW |
96KW |
|
Total power of machine |
105KW |
115KW |
128KW |
|
Weight of machine |
16000kg |
18000kg |
21000kg |
|
Overall Diamension |
16000×2700×3000mm |
16000×2900×3000mm |
16000×3100×3000mm |
