Product Specifications
Prod Model: |
LEDA-IW-P8 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Tube Chip Color: |
Full Color |
Display Function: |
Video Display |
Scanning Mode: |
1/8 Scan |
Application: |
Club |
Pixel Configuration: |
1R,1G,1B |
IP Rating: |
IP54 |
Certification: |
ETL |
Pixel Pitch: |
8mm |
Pixel Density: |
15625 |
Product Description
Product Features:
1, SMD 3-in-1 technology, LED display with vivid performance and wide viewing angle.
2, High brightness and support brightness automatically adjustment.
3, Long Lifespan, can reach more than 100, 000 hours.
4, High contrast, high refresh rate, making the LED display flicker-free when live broadcast.
5, Easy & simple installation.
6, Compatible to many signal sources such as AV, S-video, DVI, VGA, YPbPr, HDMI, SDI, DP, MOV, MPG, NTSC/PAL and etc.
7, Superior Components used only, guaranteed the displays' long lifespan and low maintenance cost.
8, Convenient Servicing: Front or rear cabinet access make the maintains work very convenient and low miantienance cost.
Application:
Advertising media, stage, stadium, exhibition, TV-show, shopping mall, banks, schools, bus station, airport, gym, factories, hospitals, bars, etc.
Item |
Parameters |
Module |
Model No. |
LEDA-IW-P8 |
Pixel Pitch |
8mm |
LED Type |
SMD 3 in 1 |
Pixel Configuration |
1R1G1B |
LED Driving Method |
1/4 Scan |
Module Pixel |
32*16(W*H) |
Module Size |
256*128MM |
Cabinet |
Cabinet Pixel |
96*96(W*H) |
Cabinet Size |
768*768MM |
Cabinet Weight |
35KG(Iron Cabinet), 25KG(Alu. Cabinet) |
Serviceability |
Front or Rear |
LED Display |
Max. Power Consumption |
≤1000W/sqm |
Ave. Power Consumption |
≤350W/sqm |
Hor. Viewing Angle |
140° |
Verti. Viewing Angle |
140° |
Brightness |
≥1500 cd/sqm |
Pixel Density |
15625/sqm |
Contrast Ratio |
1500:1 |
Processing |
16 bit |
Colors |
281 trillion |
Refresh Rate |
≥1000HZ |
Frame Rate |
60fps |
Lifetime |
100,000 hours |
Power |
AC220/110 ± 10%, 47~63Hz |
Operating Temperature |
-20ºC to +60ºC |
Operating Humidity |
20% to 90% |
Brightness Level |
Manual 100 levels,automatically 16 levels |
Certifications |
CCC, FCC, CE, ROHS, UL, ETL |
LEDA Optoelectronics Co., Ltd is a Professional, Responsible and Honest LED Display Products manufacturer.
Located in Shenzhen China, LEDA is a high-tech enterprise specializing in research, design, manufacture and sales of all kinds of LED display products. We excel at providing LED display solutions with intelligent software controls for commercial industry, residential industry, service industry, entertainment industry and etc.
LEDA believes Products Quality not only means LED Displays Quality, but also Service Quality, Price Quality, LEDA values them all.
Since the establishment of LEDA, we committed to "provide most reliable quality products with most competitive price and fastest service" to our clients, and we are working for it all the time in practice. From raw materials' selection, products' prodution, products' test and shipping, we carry out every step serious and strictly according to ISO9001: 2000 quality control system. We are also dedicated to provide trust, responsible and fast service for our clients. Besides, we provide most competitive price based on our OEM service. Till now, our products are exported to many overseas customers, like Germany, UK, Italy, Brazil, Panama, Iran, Dubai, Egypt, Slovakia, Albania, Thailand, Philippines, Signapore, Indonesia, South Africa, Poland, Australia, Russia and etc, and enjoy good repuation for its added value.
LEDA product lines cover outdoor and indoor LED displays for advertising, sports, stage, rental use...., mainly as follows:
Perimeter LED display screens, Cube LED Display screens, Live-broadcast LED display screens
Outdoor and Indoor advertising LED display screens
Stage LED display screens, Curtain LED display screens
Rental LED display screens
Truck LED display screens, Mobile LED display screens
Front access LED display screens
Arc LED display screens and other creative LED display screens
LED Moving Sign
Tri-color LED display screens
LEDA has always adhered to market-oriented, technology as the core and customer-centric. We are sincere to invite you entering long-term and stable cooperation with us.
