Lgu-Jh Clamp Type Annular Orifice Plate-Differential Pressure Flow Meter

Lgu-Jh Clamp Type Annular Orifice Plate-Differential Pressure Flow Meter
Price: US $ 130/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Western Union
1.Application and characteristics
LGU-JH clamp type annular orifice plate
Clamping type annular orifice plate is combined with the technical advantages of the circular orifice and the target type flow meter. Is a new developed low cost, good accuracy and long stability throttling device. it has the above advantages and can replace the segment orifice plate and eccentric orifice don't need a long straight pipe and has simple structure, apply to big diameter piping flow measurement such mixed furnace gas, flue gas and hot air heating furnace flow when the performance is more outstanding.

2.
Structure features
Ring groove flow sensor's throttle body is like a spindle, installed along the measuring pipe center. Perfect streamline, can completely avoid the flow separation, and minimizes the resistance to flow. high pressure hole set at pipe wall of Ring groove flow sensor spindle head, low pressure hole set at middle-rear part of annular groove way.

Accuracy
±0.2%~±0.5%
Repeatability
±0.1%

Nominal diameter
DN30 ~ DN1500
Nominal pressurePN≤50Mpa
Test mediumgas, liquid, steam
Connection modethread, flange, welding connection
Connection sizeL = 3.5 ~ 5.0 X nominal diameter D
Prod Model: LGU-JH
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Ex-Proof: Intrinsic Safety/ Explosion-Proof
LCD: Yes/No
Medium: Liquid, Air, Gas
Pressure: Suitable for Very High Pressure
Signal: 4-20mA, Pulse, RS485, Hart
Type: Differential Pressure Flow Meter
