< Lisheng>Super High Speed PP Woven Sack Flexo Printing Machine

Name: Super High Speed PP Woven Sack Flexo Printing Machine
Brand: china-manufacturer-directory.com
SKU: 709021735
Availability: InStock
Rating: 4.7 (99 reviews)

< Lisheng>Super High Speed PP Woven Sack Flexo Printing Machine

Price:	US $ 40000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1set
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Product Specifications

Prod Model:	YTB
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	CE
Color & Page:	Double Faced Multi Colors
Plate:	Flexo Printer
Embossing Structure:	Flexo Printer

Product Description

< Lisheng>Super High Speed PP Woven Sack Flexo Printing Machine

Application:
Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Performance and Features:
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops. 6. 360°continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
9. Magnetic powder brake for unwinding tension control,magnetic powder clutch for rewinding tension control.

print sample :

Model of Machine	YTB-6600	YTB-6800	YTB-61000
Max. Width of Printing Material	600mm	800mm	1000mm
Max. Printing With	560mm	760mm	960mm
Length Range of Printed Product	191-1100mm	191-1100mm	191-1100mm
Max. Diameter of Roll Material	φ 450mm	φ 450mm	φ 450mm
Printing Speed	5-120m/min	5-120m/min	5-120m/min
Thickness of plate(Including Two-sides Glue Paper)	2.38mm	2.38mm	2.38mm
Total Power	13kw	15kw	18kw
Weight of Machine	3500kg	4200kg	5000kg
Overall Dimensions	3900× 1660× 2950mm	3900× 1860× 2950mm	3900× 2060× 2950mm
