Product Specifications
| Prod Model: |
RD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Sand, Mineral Drying |
| Structure: |
Rotary Type Drier |
| Heating Mode: |
Transmission |
| Operational Method: |
Continuous |
| Operation Pressure: |
Atmospheric Dryer |
| Movement Way: |
Combined |
Product Description
Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer
Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer is widely used for drying materials in industries like cement, mine, building materials, chemistry, food and fertilizer, etc. This Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drying machine comes with thermocouples on the feeding and discharging device to control the temperature. Thermometers are also adopted so as to better control the working temperature (generally 350-380° ) of the Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drier.
Manure Drying Machine/Rotary Drier/3Drum Sand Dryer Components:
Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drier is mainly composed of cylinder, under frame, feeding and discharging devices, transmission device, gear cover, etc. (Optional auxiliary equipment includes combustion chamber, feeder and discharging device, and dust collection equipment). .Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drier manufactured by us adopts new lifting plate, which is of functions like guiding, current-sharing, and material raising. The materials are raised and evenly drop so that they are in full contact with heat for better drying efficiency. Our Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drier is designed with the best working conditions, which enables it to save 10-15% of energy and increase 10-15% of productivity compared with common dryers.
Manure Drying Machine/Three Drum Sand Dryer Working Principle:
The auto-combustion device provides heat resource for our rotary drier, which adopts down-flow heating method. When the mineral materials are fed into the cylinder, it flows down as a result of gravity. Meanwhile, they are repetitively scattered in the air so that they are in full contact with the hot air. The material is thus dried gradually.
Esong is a China Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drier manufacturer located in China's largest city, Shanghai. Surrounded by convenient transportation possibilities by land, sea, and air, we can reduce the shipping cost for our clients.
At Esong, we can provide full specifications of large and medium-sized mineral machinery, metallurgy equipment and building materials equipment, such as crushing machines, mineral processing equipment, cement production lines, rolling mill equipment, etc. These mining crusher machines are reliable in quality and low in cost. Welcome Manure Drying Machine/Coal Rotary Drier/3Drum Sand Dryer/Rotary Drier manufacturer and purchasers all over the globe to contact us!
| Model (mm) | Inclination (%) | Rotate speed (r/min) | Air inlet temperature (°C) | Power (kw) | Production capacity(t/h) | Weight (t) |
| Φ600x6000 | 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
| Φ800x8000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
| Φ800x10000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
| Φ1000x10000 | 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
| Φ1200x10000 | 3-5 | 3-8 | ≤700 | 7.5 | 1.8-5 | 14.5 |
| Φ1200x12000 | 3-5 | 3-8 | ≤700 | 11 | 2-6 | 14.8 |
| Φ1500x12000 | 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
| Φ1800x12000 | 3-5 | 2-6 | ≤800 | 18 | 5-12 | 25 |
| Φ2200x12000 | 3-5 | 1.5-6 | ≤800 | 18.5 | 6-15 | 33 |
| Φ2200x18000 | 3-5 | 1.5-6 | ≤800 | 22 | 10-18 | 53.8 |
| Φ2200x20000 | 3-5 | 1.5-6 | ≤800 | 30 | 12-20 | 56 |
| Φ2400x20000 | 3-5 | 1.5-5 | ≤800 | 37 | 18-30 | 60 |
| Φ3000x20000 | 3-5 | 1.5-5 | ≤800 | 55 | 25-35 | 78 |
| Φ3000x25000 | 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 104.9 |
Henan Dajia Mining Machinery Co., Ltd (the former Henan 3rd Machinery Factory founded in 1902) is one leading manufacturing enterprise in China and the key enterprise in mechanical industry and Zhengzhou City. After joint-stock system reform, Henan Dajia Mining Machinery Co., Ltd is established, focusing on the design and manufacture of mining machine, complete preparation equipment, rotary kiln and construction facilities, etc. With the advantages of many years' Development, we now have rich experience and powerful strength in independent design and manufacture of stone crusher, ball mill, ore separator and complete plants of cement production, limestone production and ceramsite production, and we have also passed international quality system certification.
Our products are widely applied in industries such as mining, manufacturing, mineral concentration, metallurgy, chemicals, water conservation, road and bridge constructions. Now we become the local largest manufacturer of complete ore concentration plant. With the advanced inspection equipment and strict quality guarantee system, we passed the ISO9001 certifications early in 1997 and passed ISO9001: 2000 certifications in 2003.
Currently, we have built a full product chain of 5 series with near 30 kinds including stone crushing, sand making, ore separating, cement manufacturing, basing on the main products like crusher, ball mill, rotary kiln, and assisting by vibrating screen, vibrating feeder and dust collector, etc. The advantages of high technology, higher reliability and lower operation and maintenance cost make our products the leading industrial position. Our products have been used for the international mining and construction industries in more than 40 Countries. We own a sale and service team with rich experience and good technology and an integrated sale and service network. With our high quality products and sincere service, we are recognized and praised by our customers, the mining industry and our competitors.
Henan Dajia welcome everybody all over the world.
