More Powerful Rare Earth Alinco Magnet Than More Powerful

Product Description
Cast Alnico Magnet

Product Name:
Alnico Magnets, Alumimum-Nickel-Cobalt Magnets, Cast Alnico Magnets, Sintered Alnico Magnets.

Features:
An ideal material in high temperature applications, which has high operating temperature up to 550°C and above,  with excellent corrosion resistance. They can be partially demagnetized if they come in contact with other ferrous materials, special care is required during handling and storing.

Usually cast and grinded during production, they are available in various grades depending on its application. Others such as sintered Alnico have lower magnetic properties but offer higher mechanical characteristics

Characteristics

Compact crystal, high intensity
Good chemistry stability, strong anti-corrosion
Even elements, excellent and magnetic performance
Excellent temperature stability
Highest usage temperature reach 550°C

Magnetic Properties of Alnico Magnets:


Grade	Br		HcB		Hcj		(BH)max		Br	Hcj	Max Temp	MMPA
	KGs	mT	kOe	Ka/m	kOe	Ka/m	MGOe	Kj/m³	TK(Br)%/K	TK(Hcj)%/K	ºC	Equivalents
ISOTROPIC CAST ALNICO
LN10	6.5	650	0.48	38	0.5	40	1.25	10	-0.035	-0.025	450	ALNICO3
LNG12	7.5	750	0.56	45	0.58	46	1.5	12	-0.03	-0.02	450	ALNICO2
LNGT18	5.5	550	1.13	90	1.21	97	2.25	18	-0.025	0.01	550	ALNICO8
ANISOTROPIC CAST ALNICO
LNG34	11	1100	0.63	50	0.65	52	4.25	34	-0.02	0.01	525
LNG37	11.8	1180	0.61	49	0.64	51	4.63	37	-0.02	0.01	525	ALNICO5
LNG40	12	1200	0.63	50	0.65	52	5	40	-0.02	0.01	525
LNG44	12.5	1250	0.65	52	0.68	54	5.5	44	-0.02	0.01	525
LNGT34	11.5	1150	0.73	58	0.75	60	3.5	28	-0.02	0.03	525	ALNICO6
LNG52	13	1300	0.7	56	0.73	58	6.5	52	-0.02	0.03	525	ALNICO5DG
LNG60	13.5	1350	0.73	58	0.75	60	7.5	60	-0.02	0.03	525	ALNICO5-7
LNGT38	8	800	1.38	110	1.4	112	4.75	38	-0.025	0.01	550
LNGT40	8.5	850	1.44	115	1.46	117	5	40	-0.025	0.01	550	ALNICO8
LNGT44	9	900	1.44	115	1.46	117	5.5	44	-0.025	0.01	550
LNGT36J	7.2	720	1.88	150	1.9	152	4.5	36	-0.025	0.01	550	ALNICO8HC
LNGT60	10	1000	1.38	110	1.4	112	7.5	60	-0.025	0.01	550
LNGT72	10.5	1050	1.44	115	1.46	117	9	72	-0.025	0.01	550	ALNICO9
LNGT80	10.8	1080	1.5	120	1.53	122	10	80	-0.025	0.01	550
ISOTROPIC SINTERED ALNICO
FLNG10	6.5	650	0.5	40	0.53	42	1.25	10	-0.03	-0.02	450	ALNICO3
FLNG12	7.5	750	0.56	45	0.58	46	1.5	12	-0.035	-0.025	450	ALNICO2
FLNGT18	6	600	1.19	95	1.23	98	2.25	18	-0.025	0.01	550
FLNGT20	6.2	620	1.25	100	1.31	105	2.5	20	-0.025	0.01	550	ALNICO8
ANISOTROPIC SINTERED ALNICO
FLNG34	11.5	1150	0.6	48	0.63	50	4.25	34	-0.02	0.01	525	ALNICO5
FLNGT28	11	1100	0.73	58	0.75	60	3.5	28	-0.02	0.03	525	ALNICO6
FLNGT36J	7.2	720	1.88	150	1.9	152	4.5	36	-0.025	0.01	550	ALNICO8HC
FLNGT38	8	800	1.38	110	1.4	112	4.75	38	-0.025	0.01	550
FLNGT44	8.5	850	1.5	120	1.53	122	5.5	44	-0.025	0.01	550	ALNICO8
FLNGT48	9.2	920	1.56	125	1.59	127	6	48	-0.025	0.01	550
BONDED ALNICO (BEARING)
B-LNG7	3.1	310	1	79.63	1.3	103.5	0.85	6.77	-0.02	0.01	200
B-LNG8	3.4	340	1.05	83.612	1.35	107.5	1	7.96	-0.02	0.01

Two kinds of Alnico Magnet production methods:
*Cast Alnico can be made into many sizes and shapes;
*Sintered Alnico is usually restricted to smaller sizes.

However, both process lead themselves to complex geometries and configuration.
Standard Sintered Alnico has tighter dimensional tolerances due to its processing. It also has slightly lower magnetic properties, but better mechanical strength than Cast Alnico products.

Cast Alnico can be made into intricate and complex shapes, which is not possible with other magnetic materials. It is high magnetic flux density, resistance to corrosion and excellent temperature stability, the maximum working temperature up to 600°C.

Cast Alnico magnet is widely used in all kinds of sensors and meters, electronics, instruments, medical instruments, teaching, automobile, aviation, martial and other applic- ations.

So Cast Alnico magnet is much popular than Sintered Alnico magnets.

Our Services

a. Quick response:
      We commit to give you immediate detailed quotations with instructions and product
    details. And customize your required product in the shortest time.
b. High-quality products and competitive prices:
      We reduce material costs through purchase large quantitatively of raw materials and
   other measures from manufactures directly, which ensures good quality and favorable
   prices of our products, and we share our profit with customers.
c. Closed service:
     Big or long-term cooperation customers can become our VIP customers and enjoy more
   competitive prices and VIP service.
d. Various transportation

 FAQ
1. What is the way for payment?
A:We can accept T/T, L/C, Western Union,Paypal

2. What about the delivery time?
A: 1) If the goods are in stock, we will send the goods after we sign the contract and decide the best payment.
     2) If the goods are out of stock, the goods should be produced from raw material to shipping. The delivery time is about 10-25days.

3. How do we transport?
A: According to your request. Such as by sea, by air, by international express.

4. What are our main products?
A: Ndfeb, Alnico, Smco,Ferrite and magnetic assemblies are our main products.
5. Did we have the exhibitiones?
A: yes, we had the exhibition in America, Germany, Guangzhou. And we always view the exhibitions in various cities.

6. What is normal dimension of our products?
A: All magnets are customized.

7. What information do I need to supply when I have an inquiry?
A: 1) Material type and grade required.
     2) Size and shape, if available, a sketch or drawing with dimensions and
         tolerances.
    3) Max working temperature.
    4) Delivered magnetized or unmagnetized? Magnetization direction?
    5) Quantities required.
    6) Coating required (if necessary)
    7) Information on what's the application of the magnet.

8. Why should I choose you? (Our advantages)
A: 1) Over 10 years experience in magnet field.
     2) Very fast delivery, commonly 10-25 days
     3) Samples and small orders are available
     4) All the inquiries, questions and emails will be replied within 24 hours
     5) May stock material for stable production
       6) Professional shipping forwarder to help to deliver magnets, by sea, by air
         and by express courier are all no problem
9. How is the price?

A: As we believe the quality is the most important, we will provide the high
    quality magnet with reasonable price.

10. Are you the Manufactory in China?
A: Yes.
 You can contact me if have any other questions! You are always welcome!
