Product Specifications
| Prod Model: |
TQ-0.5 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Extractor |
| Shape: |
Wimble Type |
| Capacity: |
100L-20000L |
| Application: |
Food, Chinese Medicine, Aromatic Oil, etc. |
| Type: |
Pharmaceutical Packaging Machinery |
| Finished Dosage Form: |
Liquid |
Product Description
Multi functional extracting tanks
SUS304 or 316L used
Applicable to food, pharmaceutical, chemical industries.
Equipment characteristics:
1. The equipment is applicable for the multiple technology operation of normal pressure, micro pressure, water frying, warm soaking, thermal reflux, compulsory circulation, filtration, redolent oil extraction and organically solvent recycling in traditional Chinese medicine, food and chemical industry.
2. The tank body is equipped with CIP cleaning automatic rotary spraying ball head, temperature measuring hole, explosion-proof view lamp, view mirror, rapid open feeding inlet etc., which can guarantee the convenient operation and is in accordance. With GMP standard.
3. The tank body inside the equipment is made of imported SUS304, and the jacket is made of completely sealed aluminum silicate blanket for temperature holding. The external tank body is stuck with SUS304 semi-luster thin steel sheet for surface decoration.
4. The complete equipment supplied shall include: Defoamer, condenser, cooler, oil and water separator, filter and control desk for cylinder etc. Accessories.
Multi functional extracting tanks
Wenzhou wanyuan food machinery factory
The following is a parameter of Extracting Tank:
| Specification/Model | TQ-0.5 | TQ-1.0 | TQ-2.0 | TQ-3.0 | TQ-4.0 | TQ-5.0 | TQ-6.0 | TQ-8.0 |
| Volume (L) | 560 | 1300 | 2300 | 3600 | 4400 | 5560 | 6500 | 8900 |
| Designed pressure of tank (Mpa) | 0.09 |
| Designed pressure of jacket (Mpa) | 0.3 |
| Heating area (m2) | 2.1 | 4 | 5 | 6.8 | 7.3 | 8.5 | 9.5 | 11 |
| Condensation area m2) | 3.0 | 5.0 | 6.0 | 8.0 | 10.0 | 12.0 | 15.0 | 20.0 |
| Cooling area (m2) | 0.5 | 0.5 | 1.0 | 1.0 | 1.0 | 1.5 | 2.0 | 2.0 |
| Diameter of charging port ( mm) | 350 | 350 | 400 | 400 | 450 | 450 | 450 | 500 |
| Diameter of slag port (mm) | 600 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1200 |
| Steam consumption (Kg/h) | 150 | 245 | 325 | 345 | 525 | 575 | 645 | 720 |
| Cooling water consumption (T/h) | 3.0 | 5.0 | 6.0 | 7.0 | 8.0 | 9.0 | 10 | 12 |
Our factory specializes in producing and selling processing equipment for dairy products, beverage, brewage, meat and poultry. Our main products include automatic double-tank sterilizing boilers, electric heating sterilizing boilers, emulsifying tanks, sugar dissolving tanks, cooling and heating cylinders, concentrating boilers, seed tanks, jacketed boilers, and direct cooling tanks.
Other food equipment can also be designed and manufactured according to customer requirements. The latest digital technology has been utilized for direct conversational programming and key parts have been carried out in mechanical machining, such as drilling, cutting, milling and grinding to ensure the ultimate precision. We have powerful technical force to independently and successfully design and manufacture products, completely realizing the simple and programmable operations of consistent products. We have some experienced experts and they can provide whole services for you from initial preparation, detailed construction and after-sales technique to spare part support.
At the same time, we combine our many years' experience to meet customer requirements and solve the difficulties of equipment technology. All our stainless steel equipment have reached sanitary equipment standard, which guarantees users with completely sanitary status through our abundant strength and a good reputation. We offer customers safe and reliable products and favorable prices.
