Product Specifications
Prod Model: |
56Frame motor |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Frame48,56.56h,143t,145: |
2poles, 4poles |
220/440V: |
230/460V |
IP22,IP44,IP55: |
Temperature Rise B,F,H |
NEMA Motor: |
C Face |
Rigid Base: |
Tefc,Teao.Tenv,Odp |
Application: |
Power Tools |
Operating Speed: |
Constant Speed |
Number Of Stator: |
Three-Phase |
Rotor Structure: |
Squirrel-Cage |
Casing Protection: |
Closed Type |
Starting Mode: |
Direct on-line Starting |
Species: |
NEMA Motor |
Brand: |
Kapteeni |
Product Description
NEMA Standard Three Phase AC Electric Motors' Feature: This NEMA standard series motor is designed and manufactured according to the USA NEMA standard and Canada standard. Novel pattern, excellent technics, reliable performance, low temperature,; Oe noise, high efficiency.
Usage Range: Suitable for air compressor, small machine tool and other fields requiring higher starting torque. The capacitor-running motor is suitable for ventilation, medical instrument and the fields of light and none loading start.
Rated Voltage: 208-230V/460V Rated Frequency: 60Hz
Quick Details
- Brand Name: XIAOLAODA&KAPTEENI
- Model Number: YE2/YE3/NEMA/Y2/Y/YL/YC/YY/MY/MY/ML/MS
- Type: ac motor
- Frequency: 50Hz or 60Hz
- Output Power: 0.09kw to 75kw
- Protect Feature: Totally Enclosed/OPEN
- Phase: Three-phase/Single phase
- Certification: CCC, CE, ROHS,ISO9001
- AC Voltage: 110V,220V,380V,415V,660V
- Place of Origin: Taizhou, China (Mainland)
- Efficiency: IE3/IE2/EFF1/EFF2
- Insulation class: Class B, F,H
- Protection grade:IP22,IP44, IP55
- Duty: S1,S2,S3
- Mounting: B3,B14,B5,B35,B34 etc
- Cooling: ICO141
- Bearings: C&U,SKF,NTN,NSK Products:Motors,also Pumps
Packaging Details: | Cartons, Wooden crates, Pallets |
---|
Delivery Detail: | 10-30days |
---|
Electric Motors with CE
Features:
1) Utilizes IP55 enclosures
2) Multiple feet locations
3)Cast iron, Aluminum frame, end shields and base
4) High strength cable gland
5) Shaft key and protector supplied
6) Superior paint finish
7) Motors are made to heavy duty service factors
8) Can be made with stainless steel shaft
9) Motors made for continuous S1duty,also ok with S2.S3 duty.
10) Utilizes vacuum impregnated Class F/H insulation
11) High performance and efficiency
Advantages:
1) Water, dust and vermin resistant
2) Quiet operation
3) Electricity saving
4) Easy installation (bolt on feet or brackets as required)
5) Corrosion resistant
6) Dependable
7) Superior life
8) Reliable in country, city or factory environments
Enclosure: | IP22/IP44/IP54/IP55 |
Insulation: | Class B, F,H |
Working Duty: | S1,S2,S3 |
WHY CHOOSE US
WHAT WE DO INSIDE HUAMING COMPANY
- Stamping of lamination
- Rotor die-casting
- Winding and inserting - both manual and semi-automatically
- Vacuum varnishing
- Machining shaft, housing, end shields, etc
- Rotor balancing
- Painting - both wet paint and powder coating
- Motor assembly
- Packing
- Inspecting spare parts every processing one by one
- 100% test after each process and final test before packing.
WHAT HUAMING CAN DO FOR CUSTOMERS
- We supply standard products to customers.
- We supply standard products under customers' brands and packaging, etc
- We have our own R&D departmen cant develop new products according to customers'requirements.
OUR FACTORY CAPABILITY
- Established:1985
- Total : workshop, laboratory and office all building belongs to ourselves.
- Employees: All with more than 8 years experience,and some with more than 30years.experience.
- Engineers: 5 work in R&D and 6 in factory production
- Main market: Europe,Australia,South&North America,Africa,Asia,Latin..
- Production certification: Motors has been certificated according to ISO9001, TUV, CE, CCC,Our products are made according to RoHS and IEC standard,NEMA standard..
Zhejiang Huaming Electric Motor Co., Ltd founded in 1985 year, is located in Wenling city. Closes to 104 National Road, 15 minutes' driving to the Wenling Railway Station, high-speed road junctions and 30 minutes' driving to Huangyan airport, Only 3 hours'way to Ningbo Port.
The company is an enterprise covering design, production and sales, produce "XIAOLAODA" brand products, there are EU IEC standard three-phase electric motors Y, Y2, YD, YVF, YB2, YS series, single-phase motors YC, YL, YY series, and the USA NEMA standard single & three-phase motors, also many derived motors (meat machines motor, fruit juicer motors, food processing motors, etc ). Also we product submersibel pumps as QY, QX, WQD, IRG four series. We achieved a "national industrial product production license", "export product quality permit" and the products certificates, such as CCC, ISO9001, CE, TUV, and we can apply UL certificate for clients.
Our products are very popular in China, we have Right to Import and Export, we also widely export to Europe, Australia, and America market.
Any interests or doubts, Please Kindly contact us, the good cooperation come from this moment.
