New 8 Color Belt Drive High Speed Flexographic Printing Machine

Product Specifications

Prod Model:	CJ888 series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Print Color:	8color
Anilox Roller:	Steel or Ceramic Anilox Roller
Tension:	Automatic Tension Controller
EPC:	Auto EPC
Printing Roller Lift Up And Down:	by Automatic Hydraulic
Normal Print Speed:	10-70m/Min
Style:	Relief Printing Press
Structure:	Rotary Printing Press
Color & Page:	Multi-Colour Printing Press
Usage:	Plastic Film Printing
Print Interface:	220V/380V,3p,50/60Hz
System Supported:	220V/380V,3p,50/60Hz

Product Description

New 8 color belt drive high speed flexographic printing machine


Changhong Machinery Company is mainly engaged in design and manufacturing of printing machines. It is capable of independently developing new flexographic printing machines.

Machinery products developed in the recent years, we have many kinds machine, such as normal-speed 10-60m/min, Middle-speed 10-100m/min, , high-speed over 120m/min standards.

The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
If need any video or data about our machine, pls contact Linda wu: 0086-18857728175!


1. The main features:
1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for group control.
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll


2. Machine process:
Unwinding unit-----auto tension controller for unwind ------EPC for correct position ---------Flexo printing -----------Heating and drying -------Rewinding Unit


3. Machine different requires:
1) machine width require:
Standard: 600, 800, 1000, 1200, 1400, 1600mm
Special: 1800, 2000, 2200, 2400m, 3200mm etc.

2) machine speed require:
Standard / normal speed: 10-60m/min
Middle speed: 10-90m/min
High speed: 10-130m/min

3) machine printing material require:
Standard: For plastic film, PE, PP, OPP, HDPE, LDPE, etc. And 30-150gsm paper
Standard 2: Only for paper, 50-350gsm
Standard 3: Only for non woven material
Special: For alumnium foil, pp woven bag etc.

If you want to talk further about machine you require, pls contact Linda wu: 0086-18857728175!

Model	CH888-600F	CH888-800F	CH888-1000F	CH888-1200F	CH888-1400F	CH888-1600F	CH888-1800F	CH888-2000F
Printing width Item	600mm	800mm	1000mm	1200mm	1400mm	1600mm	1800mm	2000mm
Printing color	PC:8+0;7+1;6+2;5+3;4+4
Printing length	7.5"-40"
Printing plate lifting system	Hydraulic press control
Mechanical speed	90m/min
Printing speed	10-70m/min
Anilox cylinder	Metal: 10DK-120DK Or ceramic anilox roller:300-800LPI
Register precision	Longitude:±0.20mm  Transverse:±0.20mm
Rewinder/Unwinder DIA	ø 600mm/ ø 800mm/ ø 1000mm/ ø 1200mm
Electrical header	20KW	22 KW	24 KW	26 KW	28 KW	30 KW	32KW	34KW
Bearing	Japan(NSK)
Unilateral bearing	ASUN(Germany)
Weight	5500Kg	5750Kg	6000Kg	6250 Kg	6500Kg	6750Kg	7000Kg	7300 Kg
Master power	34KW	37 KW	42KW	45KW	52KW	55KW	64KW	68KW
Dimension (L×W×H)	4.8m  × 1.85m  × 3.2m	4.8m  × 2.05m  × 3.2m	4.8m  ×  2.25m  × 3.2m	4.8m  × 2.45m  × 3.2m	4.8m  × 2.65m  × 3.3m	4.8m  × 2.85m  × 3.3m	4.8m  × 3.05m  × 3.3m	4.8m  ×  3.25m  × 3.3m
If you need other machine width or high speed 10-120m/min machine,  pls contact Ms Linda 0086-18857728175 directly.   If you have any other special require, also can contact Linda  ! ! !
