Product Specifications
| Prod Model: |
PNF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
CE |
| Type: |
Tank Reactor |
| Condition: |
New |
Product Description
INTRUDUCTION:
The PerMix PNF series Nutsche Filters are specially designed for solid - liquid separation. They are designed based on the principle of the well-known laboratory Buchner Funnel, but usually operating under either vacuum or pressure for many industrial applications.
By adding a heating system to the side walls and/or introducing a heated agitator, the PerMix PNF series Nutsche Filter can be transformed into a highly efficient Filter - Dryer, which can process a concentrated slurry and discharge a dry powder.
The PerMix PNF series Nutsche Filter is designed as a versatile several-in-one system to perform a multitude of tasks including reaction, filtration, caking washing, and thermal drying, within a single unit.
APPLICATIONS:
The range of PerMix PNF series Nutsche Filter is widely used in industries of fine chemical, pesticides, wastewater treatment, dyes and pharmaceuticals. To meet the demanding requirements for filters used in the manufacture of pharmaceutical ingredients, the PerMix PNF series Nutsche Filter is designed to meet stringent cGMP and FDA guidelines.
ADVANTAGES:
Some advantages of our PNF series Nutsche Filter including but not limited to:
1. Excellent cleanability capabilities using CIP systems
2. An open filter base providing good access to the filter internals for cleaning and inspection
3. Highly efficient drying due to unique underplate heating system
4. Easily interchangeable filter plates, with flat, homogeneous filter surfaces for good cleaning and inspection
5. Multilayer and/or conventional filter materials and good drying performance with special agitator design, large heat exchange areas
6. Suitable for handling flammable, toxic, corrosive materials with extremely safe design
FEATURES & OPTIONS:
- Construction Material & Finish
We are able to offer our PNF series Nutsche Filter with contact part to be built in SS304, SS316/316L, Titanium, Duplex stainless steel, Hastelloy, etc. Standard of internal and external finish can be adopted to the customer's needs.
- Feeding & Discharge Sealing
A variety of feeding methods can be selected by the customers. PerMix PNF series Nutsche Filter is designed for side discharge valve by hydraulic operation, with metal to metal sealing, scraper sealing by PTFE / O ring, and Easy clean type.
- Filter Base Assembly
The removable filter base can be connected with either clamps or bayonet locking system and other types.
- Drive System
Drive system by geared motor, Ex proof or ATEX standard, or Hydraulic drive system all are available to fit the special requirements of our customers.
- Vacuum Drying
As mentioned above, PNF series Nutsche Filter can be supplied with all the required features to make the filter into an efficient dryer, including all types of heating systems, vacuum execution up to almost absolute vacuum, heated or non-heated built-in filter with back pressure cleaning, and other special features according to our customer's needs.
- Spray Nozzle
Liquid usually is added into the Nutsche Filter by spray nozzles on the top, for better cake washing/CIP cleaning.
- Sizes
Standard size range of PerMix PNF Nutsche Filter from 400 to 3000 mm bottom plate, with bigger size available as per request
PerMix is a Chinese-Israeli cooperative venture with the famous Srugo family in Israel, who has been active and reputed in industrial mixing and processing equipment since 1954. PerMix's strong advantages over other competitors are 60 years of Designed-in-Israel know-how along with competitive Made-in-China prices!
PerMix has two business sections, one is Liquid Mixing Equipment, and the other is Powder Mixing & Kneading Equipment.
PerMix (Liquid) is dedicated to design and manufacture a broad range of liquid and paste mixing equipment and systems for applications of agitating, high shear mixing, homogenizing, emulsifying, suspending, dissolving, powder dispersing, serving the industries of food and beverage, cosmetics and pharmaceuticals. All products are designed to meet the strict hygienic request for those industries. The product range includes: High shear mixer, Inline mixer, Shear pump, Powder/Liquid mixer, Agitators, Contra rotating mixer, Jet agitator, Vacuum deaerator, Rotary lobe pump, etc.
PERMIX (Powder) is your professional and reliable supplier of powder mixers, paste mixers, kneaders, and other processing equipment for any industry! Our full range of equipment and system covers almost all those popular and well-proven methods to deal with mixing issues with powder and paste for food, cosmetics, pharmaceuticals, chemical, plastic, construction, etc. The product covers: Ribbon mixer, Ploughshare mixer, Paddle mixer, Continuous mixer & dryer, Dual-shaft paddle mixer (Forberg mixer), Conical screw mixer (Nauta mixer), Double cone mixer & V blender, Double arm kneader (Sigma kneader), Double planetary kneader, etc.
As one of PerMix's affiliated company, ZJY Shanghai is the expert in bulk handing equipment and systems with solutions for conveying, filling, emptying, filtering and sieving purpose for a variety of industries. With our years of experience in this filed, ZJY obtains state of art technologies and has the capacity to design, manufacture tailor-made solutions to satisfy every individual requests from our customers in China and from abroad. ZJY's product includes: Vacuum conveying system, Big bag unloader, Bag dump station, Automatic bag opening machine, Bulk bag filler, Flexible screw conveyor, Tubular chain conveyor, Filtering & Sieving equipment, Weighing & Dosing system, etc.
