Shaft diameter 6mm, housing diameter40mm
ELECTRICAL SPEC
Output circuit
Open collector NPN output
Voltage output
Push pull output
Line driver output
2000 Pairs Sells per Month
5 pairs MOQ
48-72 hours delivery after received money
| ELECTRICAL SPEC |
| output circuit | open collector NPN output | voltage output | push pull output | line driver output |
| supply voltage | 5-24 | 5-24 | 5± 0.25 5-24 | 5± 0.25 5-24 |
| current consumption | ≤ 80mA | ≤ 80mA | ≤ 80mA | ≤ 150mA |
| load current | 40mA | 40mA | 40mA | 60mA |
| single high level | min Vcc*70% | min Vcc-2.5V | min Vcc-1.5V | min 3.4V |
| single low level | Max 0.4V | Max 0.4V | Max0.8V | Max 0.4V |
| rising time Tr | Max 1us | Max 1us | Max 1us | Max 200ns |
| declining time Tr | Max 1us | Max 1us | Max 1us | Max 200ns |
| response frequency | 300kHz | 300kHz | 300kHz | 300kHz |
| MECHANICAL SPEC |
|
|
|
| number of pulses | starting torque without sealing | Max load permitted on shaft | shock resistance | vibration proof |
| 2500 | ≤ 0.05Nm | radial 50N, Axial 20N | 50G /11ms | 10G 10-2000Hz |
| rotational inertia | Working temperature | Storage temperature | Protection class | Weight |
| 4x10 -8 kgm 2 | - 30 ~ 85 C | - 35 ~ 95 C | IP65 | 100g |
