P6K(L)/P10K(L) ONLINE HIGH FREQUENCY UPS
Function Features
True double-conversion online UPS
DSP technology guarantees high performance
Output power factor 0.8
Standard backup UPS and long backup UPS in one integrated unit
Adjustable charging current via LCD or software(0.5A-6A)
Wide input voltage range(110-300VAC)
Active Input power factor correction 0.99
Emergency power off function(EPO)
| MODEL | P6K(L) | P10K(L) |
| PHASE | Single phase with ground |
| CAPACITY | 6000VA/ 4800W | 10000VA / 8000W |
| INPUT |
| Nominal Voltage | 208/220/230/240VAC |
| Input Voltage Range | 110-300 VAC at 50% load ,178-300 VAC at 100% load |
| Frequency Range | 46~54Hz or 56~64Hz |
| Power Factor | >=0.99@ Nominal voltage(100% load) |
| OUTPUT |
| Output Voltage | 208/220/230/240VAC |
| Voltage Regulation | ±1% |
| Frequency Range(Synchronized Range) | 46~54 Hz or 56-64 Hz |
| Frequency Range(Batt. Mode) | 50 Hz or 60Hz ±0.1 Hz |
| Current Crest Ratio | 3 : 1 |
| Harmonic Distortion | <=3% THD(Linear Load), <=5% THD(Non-linear Load) |
Transfer
Time | AC to DC | Zero |
| Inverter to Bypass | Zero |
| Waveform(Batt. Mode) | Pure Sine wave |
| EFFICIENCY |
| To AC Mode | 92% | 90% |
| To Battery Mode | 90% | 89% |
| BATTERY |
Standard
Model | Battery Type | 12V/7Ah |
| Numbers | 16 |
| Typical Recharge Time | 9 hours recover to 90% capacity |
| Charging Current(max.) | 1.0A |
| Charging Voltage | 218.4VDC±1% |
Long-run
Model | Battery Numbers | Depending on the capacity of external batteries |
| Charging Current(max.) | 1A, 2A, 4A, 6A(Adjustable) | Default:4.0A± 10% |
| Charging Voltage | 218.4VDC±1% |
| INDICATORS |
| LCD | Load level, Battery level, AC mode, Bypass mode, and Fault indicators |
| PHYSICAL |
Standard
Model | Dimension,D×W×H(mm) | 369×190×688 | 442×190×688 |
| Net Weight(kgs) | 60 | 66 |
Long-run
Model | Dimension,D×W×H(mm) | 369×190×318 | 442×190×318 |
| Net Weight(kgs) | 12 | 16 |
| ENVIRONMENT |
| Humidity | 0-95% RH@ 0-50ºC(Non-condensing) |
| Noise Level | Less than 58dBA@1 Meter |
| MANAGMENT |
| Smart RS-232/USB | Support Windows@2000/2003/XP/Vista/2008, Windows@7/8, Linux, Unix, and MAC |
| Optional SNMP | Power management from SNMP manager and web browser |
