Scope of application: The conductive nude copper wires go through the hose to circulate argon protective gas while argon-arc welding, or circulating water while heat dissipation; In line with the requirements of standard RMA/CGA for Grade R welding hose; Voltage withstanding, high insulating property, resisting ultraviolet radiation and ozone and hard wearing; More economical relative to the intermediate reinforced rubber hose.
Package:
1. See the table for available common specifications, pressure, weight, length and volume etc;
2. Standard dual protective packaging; Transparent PE film intertwined inner layer; Braided spiraled outer layer;
3. In addition, the cartons packing and pallet packing are available as the case may be, but shall be charged additionally.
|
DN |
Hose I.D |
Hose O.D |
Working Pressure |
Burst Pressure |
Minimum Bend Radius |
Weight |
Lenght |
|
inch |
mm |
mm |
MPa |
Psi |
MPa |
Psi |
mm |
kg/m |
metres |
|
5 |
3/16 |
4.8 |
12.7 |
10.5 |
1520 |
42.0 |
6500 |
75 |
0.16 |
20/30/50/100 |
|
6 |
1/4 |
6.4 |
14.3 |
8.7 |
1350 |
34.8 |
5300 |
75 |
0.19 |
20/30/50/100 |
|
8 |
5/16 |
7.9 |
17.5 |
8.4 |
1300 |
33.6 |
5200 |
100 |
0.26 |
20/30/50/100 |
|
10 |
3/8 |
9.5 |
19 |
7.8 |
1200 |
31.2 |
4840 |
100 |
0.28 |
20/30/50/100 |
|
13 |
1/2 |
12.7 |
23.8 |
7.0 |
1080 |
28.0 |
4340 |
125 |
0.4 |
20/30/50/100 |
|
16 |
5/8 |
15.9 |
27 |
6.1 |
945 |
24.4 |
3780 |
140 |
0.55 |
20/30/50/100 |
|
19 |
3/4 |
19.0 |
31.8 |
5.2 |
800 |
20.8 |
3220 |
150 |
0.69 |
20/30/50/100 |
|
25 |
1 |
25.4 |
38 |
3.9 |
600 |
15.6 |
2420 |
205 |
0.82 |
20/30/50 |
|
32 |
1 1/4 |
31.8 |
44.4 |
2.6 |
40 |
10.4 |
1610 |
250 |
1.00 |
18/20/30/40 |
