Product Specifications
| Prod Model: |
UD-3208Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color & Page: |
Single-Colour Printing Press |
| Printing Interface: |
USB2.0 |
| System Supported: |
Windowsxp64 |
| Structure: |
Rotary Letterpress |
| Plate: |
Relief Printing |
| Printing Speed: |
7.5CPI |
Product Description
Wide Format Printer (Large format solvent Printer UD-3208Q)
A: FY-3208G Large format printer using Seiko Instrument Group SPT printhead, 510 nozzles per printhead.
B: The voltage of our large format printer is able to adjust automatically depending on the temperature. This will solve the problem on nozzle clogging under huge temperature change.
C: The function of skipping white space is added to increase productivity.
D: The adjustment of bi-direction, step and carriage moving speed can be modified during printing.
E: Edge feather function can blur the pass line and feather pass edge.
F: Well designed alloy-aluminum girder is installed to decrease the noise during printing. Achieve the perfect quiet working environment.
G: Photoprint / Maintop / Wasatch software provide user-friendly interface and handy function with two types of printing.
H: 100% single color black is used on printing black text to avoid mixture of color.
I: Control system has the function of resuming printing after the power is cut off. This helps you to save unnecessary loss of cost.
J: The powerful suction fans equipped under the printing platform to avoid the collision between the carriage and the media, high resolution can be obtained
We supply quality large format printer with high quality.
Model
|
UD-3208Q Large Format Printer
|
Printhead
|
SPT510-35PL, Drop on demand Piezo Head
|
Mumber of Printhead
|
8 Heads
|
Maximun Print Width
|
3,200mm(125.98")
|
Print Speed*
|
101m 2/ hr 360X360dpi 1Pass
|
76 m 2/ hr 240X720dpi 2Pass
|
51m 2/ hr 240x1080dpi 3Pass
|
34m 2/ hr 360x1080dpi 3Pass
|
26m 2/ hr 720x720dpi 4Pass
|
Media
|
Max.width
|
3,300mm(129.92')
|
Max.Weight
|
120kg
|
Type
|
Frontlit,Backlit,Vinyl,Polyester,Window Film,Mesh,Leather,Backlit Film,Blue Back Paper^
|
Thickness
|
4mm(Max.)
|
Heating System
|
Equipped
|
Auto Media Feeding&
Take-up System
|
Optional
|
Ink
|
Type
|
Solvent, Eco-Solvent
|
Capacity
|
1L or 5L per Color Main Tank
|
Auto Cleaning System
|
Positive Pressure Cleaning,Anti-Clogging Flash Function&Capping System
|
Print Interface
|
Optical Fiber
|
Power Specification
|
AC 220V/230V 50Hz/60Hz 2300W
|
Operational Environment
|
Temperature 20°C-28°C Humidity 40%-60%
|
Compatible RIP Software
|
Photoprint,UltraPrint,Topaz,Wasatch,Caldera,Maitop
|
Dimension
&Weight
|
Machine
|
L4,520mm X W860mm X H1,340mm
|
Packae
|
L4,630mm X W880mm X H1,050mm |
We are a professional supplier for sign products in China who concentrate to develop, manufacture, export advertising equipments, consumables and other sign related products. Nearly 400 employees supply a full range solvent-based inkjet printer R&D, production, sales, service, technical support worldwide each day for our customers.
Four top supporters: Xaar/Spectra/Konica Stronge cooperation over more than ten years.
Based on 15 years of excellent service concept and experience in the advertising industry, and combined with the most outstanding global partnership, we manufacture the top digital ink jet printers in China, create wealth and bring pleasing service to our esteemed customers.
We reached consensus with British XAAR company, Japanese Konica, America Spectra company to combine the top technology with the advanced manufacturing concept, which let us formed a strong cooperation union. Now our factory has marched into the top field of the industry, leading and creating new scenes of ink jet printing industry all over the world.
We are building the first level distribution network in 46 regions of China and 50 countries of the world. We took the lead in passing ISO9001 and CE authentication by professional and authorized institutions, which laid a strong foundation for the 20 years global stratagems
Our UV flatbed Printers have been recognized to be most stable and famous brand of digital ink jet printers which satisfied each customer with best quality, most considerate service, completed approaches and fastest rising. The competition is harder than ever before, but we have won the market step by step! Five core competences build the leader image:
1. We have our own R&D team. Among them, 77.8% are doctors and postgraduates, which insures our leading technology.
2. Famous designing and manufacturing expert, work together to create excellent quality.
3. Spare parts with high accuracy and excellent quality----All key parts are offered by the best branded supplier in the world. 5 levels quality control system while purchasing to keep best quality.
4. Famous managing expert takes charge the global business and manage elites team and global distribution to promote the brand development of our company.
5. Continuous considerate service is offered to meet the needs of the customers in the whole world.
Please come by to our factory and test our machines!
You are most welcome to be our distributors there and gain mutual benefit!
