Changzhou Longsheng Machinery Co., Ltd. >> Plastic Machinery

Plastic Machinery

Plastic Machinery
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1set
Pay Type: L/C,T/T

Product Specifications

Prod Model: LSF258
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Voltage: Customized
Automation: Automatic
Structure: Horizontal
Computerized: Computerized
Plastic Type: Thermoplastic
Type: Injection Molding

Product Description

We are manufacturer of plastic machinery in China, there are five kinds of injection machine at present, and our engineers come from joint venture which specially export injection machine to Europe, they keep the technology update all the time. And we also offer customised machines.

Specifications
Injection molding machine
1. Big tie bar space and shot weight capacity
2. Most famous component parts
3. Perfect after-service
Specifications:

Injection molding machine,
Over 20 years' experience
CE, ISO9001
24 hour online service


Features of product:

1) LCD computer control with big display screen
2) Hydraulic double proportional valve
3) Hard chrome plated high tensile strength steel tie bars
4) Generous space for fitting large moulds
5) Large opening stroke
6) Two position transducers to control Clamping and Injection
7) Four stages of injecting, independent velocity and pressure control
8) Hydraulic mould height adjustment device
9) Screw cold-start prevention device
10) Melt decompression control
11) Screw back pressure control
12) Multiple hydraulic ejection
13) Differential high speed clamping
14) Centralized lubrication system
15) Low pressure mould protection device
16) Mechanical safety interlock
17) Double electrical safety interlock
18) Oil return filter
19) Oil tank with inner stainless steel container
INJECTION UNIT item unit LSF258
A B C
screw diameter mm 50 55 60
screw L/D ratio L/D 24 21.8 20
theoretical shot size cm 3 504 610 726
injection weight g 459 555 661
Injection  rate g/s 121 146 174
Plasticizing capacity
g/s

32
41 49
Injection  pressure Mpa 223 184 155
Screw speed rpm 0-190
CLAMPING UNIT Clamp  force KN 2580
Space  between tie  bars mm 560*530
Toggle  stroke mm 505
Max. mold height mm 560
Min. mold height mm 200
Ejector stroke mm 150
Ejector tonnage KN 62
Ejector number p 9
OTHERS Max.pump pressure Mpa 16
Pump  motor power KW 22
Heater  power KW 16
Machine dimension m 5.3*1.5*1.95
Machine  weight t 7.1
Changzhou Longsheng Machinery Co., Ltd locates in Zhonglou Scientech Industry Park of Changzhou, mainly produces and sells Plastic Injection Molding Machine, with high technology and reliable quality, our products are selling all over the world. We compare the price with the same quality, while compare quality with the same price, compare the service with the same quality and price, we regard it as our management tenet. We always integrate the optimized design associated with manufacture and good sales service together. We adopt 24hours-networking for sales service, all lifecycle services for products, smile is our characteristc service.

Ways to success, start from Longsheng. Longsheng Possesses solid strength, devoted to create a brand name ---Longsheng Machinery Series. The Clamp Force of our machines range from 600KN to 16800KN, Shot Weight range from 63G to 10000g, Plastic Injection Molding Machine is widely applied in the areas of automobile, mechanical, chemical, electrical, daily supplies, toys, etc.

With good quality, professional service and sincere credit, Longsheng will go along with new and old clients, to realize the complementary of each other's advantages, resource sharing and mutual benefit. Try to create a prosperous future with our customers as we always do.

Innovation is the sole of development for a company. The Sea Accepts All Things, Deriving More Things. The development of Longsheng is course of creative and exceed itself all the time. Study is the vital force of the enterprise, the Longsheng advocate study, and offer all-sided training to improve its staff. Devoted to everything on hand is the management concept of Longsheng, owning concentration and persistence, the enterprise could progress, the staff can improve themselves.
