Product Specifications
| Prod Model: |
APB-22ETD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
APB-22ETD
DC12V-24V, extension module, 14 points digital input, 8 point NPN transistor output
Features:
Main module: 12\22\24 points; Extension module: 22 points; It Is flexible for extending, and the optimal configuration: 7 I/O Extension modules, 1 voice module, and 1 SMS module; Program memory capacity: 320 FBDs, EEPROM;
It is allowed to place a Li-ion battery to power the clock;
Under the circumstance of DC12-24V, the main machine at Most has 12 voltage analog inputs 0-10V, 2 current analog inputs 0/4-20mA and 2 analog outputs 0/4-20mA;
High-speed operation: At most 4 high-speed inputs 10KHz and 2 high-speed outputs 10KHz;
MODBUS protocol, and can be connected to SH-300 (Text Panel);
New function blocks: Pulse width modulation (PWM), pulse Output (PTO), ACC, SMS and analog calculation etc.
|
Features: |
Main module: 12\22\24 points; Extension module: 22 points; It |
|
is flexible for extending, and the optimal configuration: 7 I/O |
|
extension modules, 1 voice module, and 1 SMS module; |
Program memory capacity: 320 FBDs, EEPROM; |
|
It is allowed to place a Li-ion battery to power the clock; |
|
Under the circumstance of DC12-24V, the main machine at |
|
most has 12 voltage analog inputs 0-10V, 2 current analog inputs |
|
0/4-20mA and 2 analog outputs 0/4-20mA; |
|
High-speed operation: at most 4 high-speed inputs 10KHZ and |
|
2 high-speed outputs 50KHZ; |
|
MODBUS protocol, and can be connected to SH-300 (Text |
|
Panel); |
|
New function blocks: pulse width modulation (PWM), pulse |
|
output (PTO), ACC, SMS and analog calculation etc.; |
|
Type |
Dimensions (mm) |
|
12 points main module |
71*99*90 |
|
22 points main module |
126*99*90 |
|
24 points main module |
126*99*90 |
|
I/O extension module |
126*99*90 |
|
SMS extension module |
71*99*90 |
