Product Specifications
| Prod Model: |
HX-160 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cutting Length: |
0.1~9999.99mm |
| Cutting Width: |
0.1~160mm |
| Power: |
1/2 HP |
| Voltage: |
220V |
| N.W: |
83kg |
| G.W: |
133kg |
| Measurement: |
550*550*1000mm |
| Manufacture Experience: |
30 Years |
| Cutting Tolerance: |
0.05mm |
| Material Thickness: |
0.5 Mm~15mm |
| Type: |
Polyurethane Foam Machine |
| Raw Material: |
Mixing |
| Automation: |
Automatic |
| Computerized: |
Computerized |
| Certification: |
GMP |
| Principle: |
Cut |
Product Description
Polyurethane Foam Cutting Machine
Main Technical Parameter:
Model |
HX-160 |
Voltage |
220V |
Power |
1HP |
N.W. |
90kg |
G.W. |
140kg |
Cutting Length |
0.1~9999.9mm |
Cutting Width |
1~160mm |
Measurement |
550x550x1000mm |
Features:
1. The max width: 160mm
2. Tolerence: 0.05mm, Precision: 0.1mm
3. Material thickness: 0.5mm-15mm
4. Kiss cut or cut through available
5. Under CE and ISO Certifications
6. Warranty for machine: 12months
7. Delivery time: 15days
8. Hot cut or cold cut available
9. Cut through for standard machine
10. Kiss cut is for optional
Characteristics:
1. This machine employs microcomputer controller to set belt cutting length.
2. The cutting length is accurate.
3. Operation is easy.
4. Waste rate is low.
5. Manufacturing experience: 30 years
6. Export experience: 10 years
Application:
Sizing cutting for luggage cases,pp belt, leather belt, rope belt, adhesive label,velcro,zipper,sleeve,paper,flat cable,small wire,metal film,ribbon etcs.
After-service:
1. Warranty for machines is 12 months
2. A promptly reply within 24 hours
3. Free usage training before delivering machines in factory
Here is the vedio of HX-160 Cutter machine,please kindly link.
http://v.youku.com/v_show/id_XNDU4MzcyMjI4.html
Touch Screen for easy operation
Protective cover
The position of feeding material
Sample show:
Relative more cutter machine:
Trade exhibition:
Packing detail for cutter machine
Workshop for cutter machine
FAQ:
1.Q: Are you a factory or trading company?
A:We are a factory and manufacturer
2.Q: Where is your factory located? How can I visit there?
A:Our factory is located in Room 8, No. 157, Wulian Road, Yushan Town,
Kunshan, Suzhou, Jiangsu, China (Mainland). You can fly to Shanghai airport
directly. All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:what is your main products ?
A:Those are Slititng machine,sheeting machine,laminating machine and Die cutting machine
4.Q: Which industries are widely used in of your machine?
A: Those are mainly used in forming of three industries of adhesives products, electronics, and new energy power battery. Examples of copper/aluminum foil, fabric, adhesive products, mobile phone accessories, insulation film, diffuser,
silicon rubber, automotive adhesives tapes and strip,paper etc.
5.Q:How does your factory do regarding quality control?
A:"Quality is priority. HEXIN always attach great importance to quality
controlling from the very beginning to the very end. Our factory has gained CE & ISO Certification
We also can customize according to your requirements,welcome your inquiry.
Kunshan Hexin precise machinery co. Ltd is located in Kunshan city, Jiangsu province, it's only 40 minutes' away from Shanghai Hongqiao airport by car, and 18 minutes' away from Shanghai railway station by high-speed rail. The traffic is very convenient.
We are specialized in developing, manufacturing, marketing and exporting microcomputer belt cutting machines, slitting machines, laminating machines, high precision die cutting machines. With strong technology, international quality control system and perfect after sale service, our products enjoy a good reputation both at home and aboard market.
With Japanese advanced design drawing and manufacturing technology, our machines have come up to the leading levels after continuous improvement for many years, especially in mechanical and electrical, gas and liquid fields. We own professional technical staffs, engineers, sales and after-service employees who constitute a young and well-qualified team. Our belief is "people-oriented, technology-first, integrity-centered and brand idea" and we will provide all our customers with reliable products, perfect service in order to create a brilliant future together.
Our products are widely applied in laminating, slitting and die cutting for protective materials, sticky materials, insulating materials, conductive materials, electronic materials, printing materials and so on, and sizing cutting for strings, strips, sheets, ropes, lines, belts, rolls, plates, tubes, fibre, rubber, foam, Mylar, LCD, films, tapes, PET, PVC, PC, metal foils, etc. Our machines can process all kinds of sheet materials, roll materials and so on.
