Detailed description
Advantages
*Rayfall® New Camping Lantern keeps continuous lighting while camping.
*New designed style with attractive appearance and high performance.
*Constant lighting guaranteeing stable lighting to avoid diminishing during the entire chosen burn time.
*Nichia LED light source Maximum brightness:400 lumens.
*Several lighting modes available adapt to each situation, wide beam (body) for close range lighting and spot beam (Top) for long distance.
- High (Max Power: power prioritized)
- Low (Max Autonomy: burn time prioritized)
- Strobe (for signaling one's presence, accessible at any time)
- Spot (for oriented lighting)
Easy to use
- Press-button is easy to use for modes switching, even with gloves on. - Flexible handle for easy portable carriage.
- Hanging hook design to free your hands in need.
- Wall charger for fast & convenient energy supplement.
Functions
L3R Waterproof led Camping lantern Features :
Light weight: 620g (with battery)
Brightness : 400 lumens Area light
Battery life : 24H~ 200H with 3.7V / 6000mAH Li-Ion battery
6 modes : 4 modes White lighting ,2 modes Red lighting for safety
Waterproof : IPX6
constant current circuit: Energy saving ,Efficient use of battery
One big electronic switch: easy to dim the lighting mode
Certification : CE ,RoHs
Packaging & Delivery
Packaging Detail: | Gift Box :115 x 130 x195 (mm) Inner Box : 355 x 270 x 205 (mm) ,< 6 pcs loaded > Carton : 385 x 570 x 225 (mm) ,< 12 pcs loaded > |
| Delivery Detail: | 25-30 working days after received your payment |
Product Description
Rayfall Manufacturer Hot Sale led camping light , High power led camping lamp , Plastic camping lamp, CE&RoHs Certification
Overview
Rayfall L3R is a model of lightweight portable LED plastic camping lantern . The fashionable designing can be the main trend nowadays. As the camping lantern employs 2x Cree XB-D R2 White LED and 5mm Red LED for safety , it provides 4 modes White lighting and 2 modes Red lighting, which can be chosen flexible in different conditions. Powered by 3.7V / 6000mAH Li-Ion battery, it can deliver a max 400 lumens Area lighting . Featuring waterproofing to IPX6, it can resist damp and rainy weather effectively. In addition, it has cold-resistance and impact-resistance. Usually apply to outdoor activities such as climbing, traversing, hiking, fishing etc.
Specifications
Model |
L3R Waterproof led Camping lantern |
Bulb |
2x Cree XB-D R2 White LED and 5mm Red LED |
Luminous Flux |
Max 400 Lumens |
Work Pattern |
White Lighting : Hi ,Mid ,Low ,SOS ; Red Lighting : Hi ,Flashing |
Reflector |
Orange Peel Reflector |
Lens |
PC |
Case material |
ABS+PC |
Operating Voltage |
DC 3.7~4.5V |
Battery |
3.7V / 6000mAH Li-Ion Battery |
Switch |
Electronic Touch Switch |
Waterproof |
IP66 |
Size |
68x88x150 mm |
Impact resistance |
1.5m |
Weight |
620g (with batteries) |
Accessories |
1, 3.7V / 6000mAH Li-Ion Battery 2, Hanging Hook
3, 1 piece Micro 5p charging cable |
L3R Led camping lantern detail data sheet :
ANSI/NEMA FL 1 |
White Lighting |
Red Lighting |
High |
Middle |
Low |
SOS |
High |
Flashing |
OUTPUT(Lumen ) |
400 |
148 |
20 |
20 |
2 |
2 |
RUNTIME(Hours ) |
24 |
74 |
200 |
NA |
NA |
NA |
DISTANCE(Meters) |
25 |
12 |
3 |
NA |
NA |
NA |
INTENSITY(CD) |
10590 |
4223 |
570 |
NA |
16 |
NA |
IMPACT RESISTANT |
1.5m |
WATERPROOF |
IPX6 |
ACCESSORY |
Hanging Hook ,Micro 5p charging cable |
Operation instructions
White Lighting :High - Low - SOS - OFF
Red LIghting :High -Flashing
1, Press the button within 1 second to change the modes.
2, Press and hold the button for 3 seconds to change between White light and Red light.
3, Press the button to switch off if the light stays in any mode more than 3 seconds.
4, It has Memory Mode ,will remeber the last mode.
Caution
1,Please protect light lens and skin from scuffing.
2,Please take out the battery when the light is not used for long time.
