Liquid packaging machine Description
Automatic Bag-given Filling and sealing Packaging Machine Suitable for mang different liquid food, such as shampoo, fruit juice, tomato
Main Features
1, Full automatic 8-staion intermittent rotay performed bags dispensing, opening and closing machine combines with automatic combination weigh scale filler, overhaed work platform and Z-elevator bulk feeder.
2, Safety guard protected for high speed and consistent production.
3, Heavy duty components and parts are selected for machine durability.
4, Hygienic construction and easy cleaning. Operator friendly design touch-screen control system.
5, Versatile in design, easy to link up with other down stream packaging equipment, such as liquid filler, powder filller, multiheads weigher, metal detector, checkweighter, case sealer etc.
6, Innovative and practical solution at reasonable costs.
7, Dust control and extractor system on special request.
Applications for this kind of packaging machines
Liquid: Rice wine, soy sauce, ricevinegar, fruit juice, beverages, milk detergent and so on
Typical Flow Chart
1, Giving bag
2, Hot Foil Coding
3, Bags Opening
4, Fill one consolidate
5, Fill two
6, Heat sealing one
7, Heat sealing two
8, Forming and output product
Model |
MR6/8-200Y(Main Machine) |
Bags size |
W100-200mm L: 100-300mm |
Filling Volume |
5-1500g(depending on type pf product) |
Packaging Materilas |
Zipper bag, stand-up bag, spout bags etc |
Capacity |
25-45bags/min(depending on type of product and packaging material used) |
Total power |
1.5Kw |
Weight accuracy |
Error≤ ± 1 |
ECYT-500 Canning Machine
Power supply |
220V/50HZ 110V/60HZ |
Total power |
20W |
Air pressure |
0.4-0.6mpa |
Production capacity |
10-35(bags/min) |
Scaling scope |
Error± 1% |
Scope of applicatic: |
Wash, Millet wine, Soy sauce,
Vinegar, Drink, Fruit juice,
Tomato sauce, Peanut butter, Jam,
Chill sauce, Bean etc. |
Wenzhou ECHO machinery Co; Ltd establish in 2010, is located in the important birthplace of zhe nang mode-Ruian. The company is specialized in automatic given bag packing machine and vacuum packing machine. ECHO packing machinery is a National high and new technology company combined with research, manufacturing, marketing and service, and possess the largest research and development institutions in the domestic industry, perfect production system and huge marketing service network, annual output and market share all reside the ex-row in profession.
At present, the company marketing network through the country, and exported to Europe, America, Southeast Asia, West Asia, the Middle East and other dozens of countries and regions. Our various products are applied in food, medicine, commodities, chemical industry, pesticides and other industries.
The company take "superior quality, user first, excellent service, continuous improvement" as guidance. To making incessant innovations on behalf of their customer for the mission. And in the first place through the IS09001 quality management system certification and CE certification in the industries. In the future, ECHO will develop in depth in for ares: " Technology, institution, management and culture. " With outstanding product quality and good market reputation to meet customer' S inspection!
