Product Specifications
Prod Model: |
drum wood chipper BX-215 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Model: |
Bx-215 |
Capacity: |
3-6 Tons/H |
Knife Roller Dia: |
500mm |
Knife Qty: |
2 Pieces |
Input Opener: |
400*170mm |
Input Dia: |
150mm |
Chips Size(Length): |
25-35mm |
Power: |
(45+7.4) Kw |
Rotary Speed: |
595rpm |
Overall Size: |
1800*1800*1150mm |
Certification: |
SGS |
Product Description
Professional supply practical environmental woodworking machinery wood chipper drum bark chipper
Wood chipper drum bark chipper
1. Supermatic craft
2. Good crushing effect
3. Easy operation
4. Extensive source of raw material
Introduction of drum bark chipper
Drum chipper is a big equipment which manufactures gross woods.
Drum tree bark chipper from the common drum chipper can be used in pulp and paper making plant, particleboard plant, wood pellets making plant and so on. And they are also the ideal and direct fuel for boilers or biomass boilers.
Structure of drum chipper:
The machine is made up of airframe, knife roller, and feed roller, conveyer belt, hydraulic system components and concrete-base.
Working principle:
It is the supporting base of the whole machine. On the cutter roller, there installs two or three flying cutter. Through the professoonal bolt, fixed the flying cutters on the roller.
According to the thickness of the raw materials, the feeding roller can moves up and down through the helping of hydraulic system. The satisfied chips can be discharged at the bottom of the machine through the screen. The bigger chips will be cutted again in the chamber of machine.
Features of drum bark chipper
1>Drum bark chipper can always work together with belt conveyors for feeding and discharging, so it is easy to achieve the Automation.
2>Besides this, Operation easy, maintenances simple, life long and the noise is low.
3>Output is much higher than ordinary ones, so they would be your best choice for getting wood chips.
Raw materials
Drum chipper is mainly used for preparing wood material for the production of artificial slabs. The cutted materials are orginal woods, stumps, bark, branches, cotton straws, wood processing remains(sawmill residues) and etc. The mouth of entering materials is wide, and the sources is extensive.
Our services
1. We will provide the relative consultant services and pro-sales and sale consultation and help customers choose the suitable machines.
2. After-sale and spare parts service. We will provide installation guide after sale and help customers deal with the problems will arise during the process of usage.
Company information
1>Our company is a professional supplier for pellet machine, briquette machine, pellet stove, wood crusher, sawdust dryer, and Pellet making line, briquette making line, filtration equipment, combining development, design, manufacture, sales and services.
2>It enjoys professional production technology, superior manufacturing equipment and good testing means.
If you want to keep the knives sharper when they work for a long time, you can prepare a set of knife sharpener!
If you need debarked woods, you can equip with a set of bark peeling machine
In order to make much better products(such as particleboards, furnitures)
Note:
Q: What should you tell us before sending inquiry first?
A: 1. The capacity (t/h) of drum chipper you need,
2. The type of drum chipper, with concrete-base or free base?
3. The raw material and its size.
Welcome your inquiry!
Model |
BX-215 |
BX-216 |
BX-218 |
knife roller Dia (mm) |
500 |
650 |
800 |
knife Qty (pcs) |
2 |
2 |
2 |
Input Opener (mm) |
400*170 |
540*220 |
680*270 |
Input Dia (mm) |
150 |
200 |
250 |
Chips size(Length)
(mm) |
25-35 |
25-35 |
30-40 |
Power (KW) |
45+7.4 |
45-55+9.2 |
110+12.5 |
Rotary speed (rpm) |
595 |
592 |
650 |
Capacity (t/h) |
3-6 |
8-12 |
15-25 |
Overall size
(mm) |
1800*1800*1150 |
2000*2000*1250 |
2400*2180*1500 |
Weight (kg) |
3100 |
4420 |
7120 |
