Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Garbage Truck |
Product Description
1. Model:
HDT5070ZYS(3tons)
HDT5130ZYS(5tons)
HDT55150ZYS(8tons)
2. The product has such features as large loading and delivering capacity, high-efficiency compression, large compressing force and sealed transport, which can reduce transport times and fuel-consumption.
3. The all-sealed transport mode can also reduce and prevent secondary pollution of cities and roads caused by rubbish, stinks and sewage leakage.
4. With its tail-gas emission up to the European IIstandard, the rubbish compression truck is safe and environment-friendly.
5. It is applicable to the transport of domestic rubbish from places such as cities, large stations, ports and wharfs, airports as well as densely-populated areas like industrial and mining enterprises and military units.
Parameter
|
HDT5070ZYS(3tons)
|
HDT5130ZYS(5tons)
|
HDT55150ZYS(8tons)
|
Chassis model
|
EQ3061TJ
|
EQ1126G6D16
|
EQ3141G7DJ
|
Engine model
|
CY4102BZLQ
|
EQB160-20
|
EQB180-20
|
Engine rated power(kw)
|
70
|
118
|
132
|
Outline dimension
(length×widt×height)(mm)
|
5920×2140×2500
|
7400×2485×2900
|
7500×2485×3000
|
Truck bucket dischargeable volume(m³)
|
5.5
|
10.5
|
12.3
|
Filling device volume(m³)
|
0.65
|
1.5
|
1.55
|
Loading weight(kg)
|
2700
|
5150
|
7800
|
Max. general weight
|
6520
|
1295
|
14700
|
Sewage tank volume(L)
|
370+42
|
402+52
|
402+52
|
Wheel base (mm)
|
3100
|
3950
|
3800
|
Min. turning diameter(m)
|
14
|
14
|
16
|
Max.truck speed (Km/h)
|
90
|
90
|
90
|
Hydraulic system pressure (Mpa)
|
16
|
16
|
16
|
Filling device's one-time working cycle time(s)
|
20
|
24
|
24
|
One-time discharge time(s)
|
38
|
38
|
38
|
Filling-mouth size (mm)
|
1750×750
|
1830×1000
|
1830×1000
|
Filling-mouth height (mm)
|
800
|
900
|
900
|
Fuel-consumption(L/100Km)
|
<=11
|
<=19
|
<=23
|
