Riotouch 55" 65" 70" 84" LED LCD Multi Touch Screen Smart TV Monitor Smart Classroom Education School Electronic

Riotouch 55
Price: US $ 2000/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: T/T
Riotouch 55" 65" 70" 84" LED LCD Multi Touch Screen Smart TV Monitor Smart Classroom Education School Electronic

Riotouch  all in one PC Main Features :
1.Convient Hot key : There are 18 hot keys in every side which convenient for you to use
2.Level A LED panel imported from AUO ,, Support FHD . Support windows ,android ,mac, Linux.
3. Easy for maintain , detachable touch frame , can fix the touch frame if touch get problem , helps save lots of energy and cost in after-sale .
4. International OPS mini PC connection , all cables are built-in monitor except the power cable , much safer for the users , and looks more gracious .
5. 3 years warranty for touch frame , 1 year for other parts , etc
6. Education software :  is design by our team which has many  humanized design to benefit to your class.


Specification:
LED ParametersSize69.5"
LED BrandSHARP
Packing ParametersExternal Size1651*973*107mm (without base)
Touch Size1538.8*865.6mm
Plywood Carton Size1800*290*1240mm
Net Weight72KG (without base)
Gross Weight95kg
Carton Size 1860*350*1360 +/- 50mm
Gross Weight with wooden box 135kg
Power ParametersPower< 800W
Standby Power<1W
Display ParametersActive Display Area1538.8 (H) x 865.6 (V)mm
Pixel Pitch0.802(h)x0.802(v)mm
Display Colors1.07 billion colors
Number of Pixels1920x1080 pixels
Brightness350cd/m2
Viewing Angle178 Degree
TV ParametersTV StandardNTSC M/N,PAL BG/DK/I/H,SECAM L/L
Multimedia FormatsMPEG1,MPEG2,MPEG4,H264,RM,RMVB,MOV,MJPEG
USB2.0 Multimedia PlaybackVido/Audio/Picture
USB System Upgrading OnlineSupport USB online upgrading function
ResolutionMax. 1080P format
HDMIV1.3, 720P/1080P
HDCPV1.1
3D DNRSupport video DNR
Scanning FormatSupport 1080i Video crisscross DAS (Dynamic Adaptive Scan )
Sound ControlAutomatic sound standard detection, support for balance adjustment and surround Sound
Sound Output2X10W
Input and
output ports
USB Multimedia Input ports2-line
Touchscreen port1-line USB2.0
HDMI Input port1-line
VGA Input port1-line
PC Audio port1-line
UPBRP audio and video input port2-line
AV Input port2-line
Touch
parameters
Touch TechnologyInfrared touch technology
Touch modeSingle, multipoint,Mouse click
Inductive objectsFinger,pen or any other opaque objects
Inductive sizeDiameter≥5mm
Resolution32767*32767
Response time1) First dot(click):8ms, continuously(writing):3ms
2) multipoint click:first dot(click):8ms,continuously(writing):8ms
3) Mouse click:first dot(click):8ms,continuously(writing):8ms
Cursor speedUP to 300 dots/s     Multipoint,mouse click:125 dot/s
Operating life≥60,000,000 times to click
PowerUSB power supply (4.6-5V, DC)
Power consumption≤1w
Operation SystermWindows 8, windows 7, XP, Mac, Linux
CalibrationHID devices standard, accord with Win7 multi-touch protocol, no need special software to calibrate, just use Table PC setting to finish the calibration.
Anti-light decay functionAnti-light decay circuits to prevent the performance degradation caused by long working hours
LED Test SoftwareSupply touch screen LED test software to test the function of each couple of the LED lights and the drawing functions
Antilight interference functioncan work properly in direct sunlight condition

Standard Accessories without PC
Remote ControlTV Remote control
USB cable1.5m USB cable for touch monitor, USB2.0
VGA cable1.5m VGA cable
Audio cable1.5m audio cable
CD1 pcs
Pens without ink2 pcs
Teaching Pointer1 pcs
User manul1 pcs
Wall bracketsScrews, wall mount kits
Standard Accessories  with PCRemote ControlTV Remote control
CD1 pcs
Pens without ink2 pcs
User manul1 pcs
Teaching pointer1 pcs
Wall bracketsScrews, wall mount kits

FAQ

1. Q: Are you a factory?
A: Yes, we are a factory, we have our own production line.
2. Q: what's your products' quality control?
A:  Our tenet is "Quality first, Prestige first". We are pay more attention to the beginning till the very end of the production. Our products have passed the CE & ROHS & ISO & FCC etc. certification.
3.  Q: What's your after-sale service?
A:  We can offer 100% guarantee on our product. If any problems, you will get our reply within 24 hours.
4.  Q: What's your  MOQ?
A: Generally, our MOQ is 1 pcs. But the order quantities are bigger, the discounts are bigger.
5. Q: Could you offer the OEM service?
A: Yes, we can provide the OEM service if our customer requested.
6. Q: How about the delivery?
A: The delivery would be with in 3-15 days according to the order quantity and size of the items.
Prod Model: Hv series
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Touch Points: 2 10 Points Touch
LED Resolution: 1024 X 1080
Whiteboard Touch Technology:Infrared IR: Infrared Touch Technology
Touch Frame Warranty: 3 Years
Touch Resolution: 32767 X 32767
PC Connection: International OPS Mini PC
Certification: CE, FCC, RoHS
Software: Free Education Software
Support System: Win7, Win8, Linux, Mac, Android
Usage: School, Office, Computer, Digital Whiteboad
Screen Size: >60 Inches
Aspect Ratio: 16:9
Application: Education and Training System
Screen Type: Infrared
Resistive Touch Screen Type: Digital
Customized: OEM Is Available
RioTouch is a professional manufacture of infrared touch screen, infrared frame, interactive whiteboard and touch screen kiosks. Also we have an enthusiastic team to provide you with solutions in many fields like hometheater, education, corporation, training and games. We aim to make everything easy and help you to turn your ideas and designs into reality.

RioTouch future research willmainly concentrate in the visual multi-touch technology development, interactive educational software development, interactive applications softwaredevelopment.

Riotouch is committeed to be:
1. Professional provider of human-computer interactive techniques.
2. China leading Infrared interactive whiteboard technology solution provider.
3. China leading infrared whiteboard SKD supplier.
4. China leading touch screen manufacturer
