Product Specifications
| Prod Model: |
CRL-040 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| Solution: |
Rk3188 |
| Type: |
Transmitter |
Product Description
1. Operation System: Android 4.2
2. Language: Chinese, English...Multi-Language support
3. Chipset: RK3188 28nm Cortex-A9 Quad core.
4. GPU: Embedded 3D GPU Mali 400, High frequency 500Mhz, Support OpenGL ES 1.1/2.0 and OpenVG 1.1.
5. SDRAM: DDR3 2GB(Optional: 1GB/2GB)
6. Nand Flash: 8GB Nand Flash. ( Optional: 4GB/8G/16G/32G)
7. Storage Extension: Support MicroSD(TF), Up to 32GB
8. Network: 2.4GHZ WiFi 802.11 b/g/n, LAN 10/100M Base-T
9. Camera: Support 5.0M(2.0M camera is optional)
10. MIC: Build in
11. Module: Support Bluetooth 4.0 Module
12. Power Supply: DC 5V/2A
13. HDMI Out: 1xHDMI(A type Female), HDMI1.4A Full HD 1920x1080P
14. USB Port: 2XUSB Host
15. Card Reader: 1X Micro SD card (TF card) reader
16. AV Out: 1x3.5mm Headphone Jack
17. Network: 1xRJ45 LAN Port
18. Power Supply: 1xDC Jack
19. Antenna: Build in Wi-Fi antenna
20. Audio Container: Support MP1, MP2, MP3, WMA, WAV, OGG, OGA, APE, FLAC, AAC, M4A, 3GPPetc Audio formats. Muliti -EQ mode, Support Synchronized lyrics and full-page lyric display.
21. Audio Out: HDMI/AV Data Output
22. Video Decoder: MPEG-1, MPEG-2, MPEG-4, H. 263, H. 264, AVS, VC-1,
RV, VP6/VP8, Sorenson Spark, MVC 1920x1080P 60FPS
23. Video Encoder: H. 264, VP8, MVC(1080P)
24. Resolution: Full HD1080P@30fps
25. H. 264 Data Rate: Up to 60Mbps
26. Image browser: Support JPG, JPEG, BMP, GIF, PNG, JFIFetc photo format. Maximum resolution up to 8192x8192.
27. Text-Reading: Support TXT, LRC, PDF, Html, Htm, EPUBetc formats(Depends on APK install)
28. Software Compatibility: Windows XP, Window 7, iOS, Android
29. Software Extension: Support Google Play & APK install
30. DLNA, Miracast Protocol: Support DLNA, Miracast Protocol
31. Remote Control: Support Smart phone remote control, 2.4GHZ wireless air mouse/IR Remote controller.
32. IM Software: Support Skype/QQ/MSN/GTALK (Depends on APK install)
33. Office Software: WORD/EXCEL/PDF(Depends on APK install)
